AirTAC TTH · Heavy duty Stopper Cylinder

Airtac TTH Stopper Cylinder TTH50X30KF

Genuine AirTAC heavy duty stopper cylinder, order code TTH50X30KF from the TTH range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • BoreØ50 mm, 30 mm stroke
  • StopperLever roller, adjustable oil cushion, self-lock
  • MagnetNo magnet
  • ActionSingle acting, spring extend
  • MountingFlange
  • Bore / strokeØ20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm
$148.85 $156.35Save 4%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every TTH bore, stopper and magnet on one page All TTH codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac TTH Stopper Cylinder TTH50X30KF

The AirTAC TTH50X30KF takes the Dia 50 mm, 30 mm stroke TTH heavy-duty stopper and adds the F self-lock to the K lever roller with adjustable oil cushion. Without air the spring extends the rod and the stopper rises; the self-lock then prevents the lever from springing back and pushing the stopped load backwards, which matters when a loaded pallet rests against the roller.

At Dia 50 the thicker piston rod absorbs impact better than small bores, and the oil cushion damping is adjustable because Dia 32 and above allow tuning. This build has no S magnet, so magnetic rod sensing is not fitted; the threaded proximity-sensor hole on Dia 50 to Dia 80 bores is M8x1.0. The series runs on air filtered by a 40 um element and needs no lubrication.

Airtac TTH Stopper Cylinder TTH50X30KF Technical Specifications

Order codeTTH50X30KF
ProductHeavy duty Stopper Cylinder
BoreØ50 mm, 30 mm stroke
StopperLever roller, adjustable oil cushion, self-lock
MagnetNo magnet
ActionSingle acting, spring extend
MountingFlange
Bore / strokeØ20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm
PortM5×0.8 · PT1/8 · PT1/4
Stopper typesLever roller, fixed oil cushion, Lever roller, adjustable oil cushion
FluidAir (filtered by 40 µm element)
Operating pressure0.25-1.0 MPa on Ø20, 0.2-1.0 MPa on other bores
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
CushionBumper
LubricationNot required

Source: AirTAC Products Catalog 2026A (PDF01-P0752..P0753), TTH series specifications and ordering code.

How to choose

Take TTH50X30KF over TTH50X30K whenever a stopped load could shove the lever back, since only the F option locks it. Drop to TTH50X30K if you do not need that holding, choose TTH50X30SF-style builds with S only for magnet feedback, or move to TTH50X30L for the fixed rather than adjustable cushion. Adjacent bores Dia 40 and Dia 63 keep the same 30 mm stroke, so resize using the maximum load charts for a friction coefficient of 0.1.

AirtacDistr lists every TTH order code with its price on one page at https://airtacdistr.com/products/airtac-tth-heavy-duty-stopper-cylinder

Applications

forklift

Pallet drop-off lane near forklift traffic

If a bump or an air dropout puts a loaded pallet on the stopper, the self-lock keeps the lever from being driven back into the line.

straighten

Aligning skewed loads before transfer

The lever roller with adjustable oil cushion absorbs off-centre impacts as misaligned cartons are squared against the stop.

check_circle

Hold-and-release inspection station

Air retracts the rod to release parts one by one; on supply loss the spring lift plus self-lock holds the queue in place.

FAQ

What are the key figures of the TTH50X30KF?

Dia 50 mm bore, 30 mm stroke, single acting spring extend, flange mounting, operating pressure 0.2-1.0 MPa, proof pressure 1.5 MPa (215 psi), temperature -20 to +70 C, K lever roller with adjustable oil cushion, F self-lock fitted, no magnet, ports M5x0.8, PT1/8 or PT1/4.

What does the F self-lock change compared with the plain TTH50X30K?

It stops the lever from springing back and pushing the stopped load backwards, so the load stays held. Both codes keep the adjustable oil cushion and the M8x1.0 sensor hole on this Dia 50 bore; neither carries the S magnet.
