AirTAC TTH · Heavy duty Stopper Cylinder

Airtac TTH Stopper Cylinder TTH63X30K

Genuine AirTAC heavy duty stopper cylinder, order code TTH63X30K from the TTH range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • BoreØ63 mm, 30 mm stroke
  • StopperLever roller, adjustable oil cushion
  • MagnetNo magnet
  • ActionSingle acting, spring extend
  • MountingFlange
  • Bore / strokeØ20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm
$281.45 $288.95Save 2%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every TTH bore, stopper and magnet on one page All TTH codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac TTH Stopper Cylinder TTH63X30K

The TTH63X30K steps up the AirTAC TTH heavy duty stopper cylinder to a Dia 63 mm bore while keeping the 30 mm stroke, giving more capacity for stopping heavy pallets and workpieces on conveyors. It is single acting pull-in: air retracts the rod to release the load, and when the air supply is cut the spring pushes the stopper back up, so nothing rolls past during a failure. The thicker piston rod of the series resists impact.

The K option selects the lever roller with adjustable oil cushion, adjustable on Dia 32 and above, so damping on this Dia 63 unit can be matched to conveyor speed. Leaving the magnet field blank in the order code means no magnet is fitted: reed switching of stroke position is not available, though the housing still carries a threaded hole for an M8x1.0 proximity sensor on Dia 50 to Dia 80 bores. Operating pressure is 0.2-1.0 MPa, air is filtered by a 40 um element, and no lubrication is required.

Airtac TTH Stopper Cylinder TTH63X30K Technical Specifications

Order codeTTH63X30K
ProductHeavy duty Stopper Cylinder
BoreØ63 mm, 30 mm stroke
StopperLever roller, adjustable oil cushion
MagnetNo magnet
ActionSingle acting, spring extend
MountingFlange
Bore / strokeØ20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm
PortM5×0.8 · PT1/8 · PT1/4
Stopper typesLever roller, fixed oil cushion, Lever roller, adjustable oil cushion
FluidAir (filtered by 40 µm element)
Operating pressure0.25-1.0 MPa on Ø20, 0.2-1.0 MPa on other bores
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
CushionBumper
LubricationNot required

Source: AirTAC Products Catalog 2026A (PDF01-P0752..P0753), TTH series specifications and ordering code.

How to choose

Pick the TTH63X30K when the catalog maximum load charts (drawn for a friction coefficient of 0.1) put your pallet between the Dia 50 and Dia 80 capacities: it keeps the same 30 mm stroke as the Dia 50 code but adds bore, whereas the Dia 80 code pairs its larger bore with a longer 40 mm stroke. Compared with the TTH63X30SK, this code omits the magnet, so if position switches must read the piston magnetically, order the SK variant instead; the fixed-cushion TTH63X30L is the choice when damping adjustment is unnecessary.

AirtacDistr lists every TTH order code with its price on one page at https://airtacdistr.com/products/airtac-tth-heavy-duty-stopper-cylinder

Applications

conveyor_belt

Heavy pallet gates on main transport conveyors

The Dia 63 bore gives extra stopping capacity on the 30 mm stroke, with the adjustable oil cushion lever roller absorbing pallet impacts that vary with line speed.

forklift

Load hand-off points at staging lanes

When air is cut the spring raises the stopper, so inbound loads are always caught at the hand-off; the self-lock option is available on lever rollers if loads must be prevented from being pushed backwards.

factory

Stops for machinery infeed without magnetic switching

With no magnet fitted, control of stopper position relies on the M8x1.0 threaded proximity sensor hole (Dia 50 to Dia 80 bores), keeping sensing external to the cylinder.

FAQ

What are the key specifications of the TTH63X30K?

Dia 63 mm bore, 30 mm stroke, single acting spring extend (pull-in), lever roller stopper with adjustable oil cushion (K), no magnet. Operating pressure 0.2-1.0 MPa, proof pressure 1.5 MPa (215 psi), temperature -20 to +70 C, fluid air filtered by a 40 um element, lubrication not required, flange mounting, series per JIS standards.

This code has no magnet - how can position be detected?

Because the magnet field of the order code is blank, no piston magnet is fitted, so reed switches cannot read stroke position on this unit. Instead, use the threaded hole in the housing, which accepts a proximity sensor with an M8x1.0 thread on Dia 50 to Dia 80 bores. If magnetic switching is required, order the magnet-equipped TTH63X30SK variant of the same bore and stroke.
