AirTAC TTH · Heavy duty Stopper Cylinder

Airtac TTH Stopper Cylinder TTH63X30KF

Genuine AirTAC heavy duty stopper cylinder, order code TTH63X30KF from the TTH range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • BoreØ63 mm, 30 mm stroke
  • StopperLever roller, adjustable oil cushion, self-lock
  • MagnetNo magnet
  • ActionSingle acting, spring extend
  • MountingFlange
  • Bore / strokeØ20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm
$281.45 $288.95Save 2%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every TTH bore, stopper and magnet on one page All TTH codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac TTH Stopper Cylinder TTH63X30KF

Built on the Dia 63 mm bore and its fixed 30 mm stroke, this code orders the TTH with a K lever roller, whose oil shock absorber is adjustable on Dia 32 and up, and adds the F self-lock. The lock stops the lever from springing back and pushing the stopped load backwards after impact.

The cylinder is single acting pull-in: air retracts the roller, and when the air is cut the spring pushes it back up, so the stopper rises on a supply failure. It runs on 0.2 to 1.0 MPa, works from -20 to +70 C on air filtered by a 40 um element, needs no lubrication and follows JIS standards. No magnet is fitted on this code.

Airtac TTH Stopper Cylinder TTH63X30KF Technical Specifications

Order codeTTH63X30KF
ProductHeavy duty Stopper Cylinder
BoreØ63 mm, 30 mm stroke
StopperLever roller, adjustable oil cushion, self-lock
MagnetNo magnet
ActionSingle acting, spring extend
MountingFlange
Bore / strokeØ20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm
PortM5×0.8 · PT1/8 · PT1/4
Stopper typesLever roller, fixed oil cushion, Lever roller, adjustable oil cushion
FluidAir (filtered by 40 µm element)
Operating pressure0.25-1.0 MPa on Ø20, 0.2-1.0 MPa on other bores
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
CushionBumper
LubricationNot required

Source: AirTAC Products Catalog 2026A (PDF01-P0752..P0753), TTH series specifications and ordering code.

How to choose

Choose TTH63X30KF over TTH63X30K when a springing lever must not push the stopped load backwards; over TTH63X30L if you need to tune the oil cushion rather than accept the fixed setting; and over TTH63X30SK or TTH63X30SKF when position sensing is not required, since this code carries no piston magnet.

AirtacDistr lists every TTH order code with its price on one page at https://airtacdistr.com/products/airtac-tth-heavy-duty-stopper-cylinder

Applications

conveyor_belt

Accumulation conveyor stop

Stops pallets in an accumulation lane where the adjustable oil cushion can be tuned to line speed and the self-lock prevents the roller from kicking the load backwards.

warehouse

Warehouse transfer station

Holds totes at a manual pick or transfer point; if air is lost the spring lifts the stopper and the F lock keeps it from springing back into the queue.

package_2

Packaging line gate

Acts as a fixed-position gate for cartons fed by a powered roller conveyor, with damping set at the Dia 63 bore to suit the heaviest expected pack.

FAQ

What are the key figures of the TTH63X30KF?

Dia 63 mm bore, 30 mm stroke, single acting spring extend (pull-in), flange mounting, ports M5x0.8, PT1/8 or PT1/4, operating pressure 0.2 to 1.0 MPa, proof pressure 1.5 MPa (215 psi), temperature -20 to +70 C, lever roller with adjustable oil cushion plus self-lock, no magnet.

What happens when the air supply fails?

The TTH is single acting pull-in: air retracts the roller, and the spring pushes it back up when air is cut, so the stopper rises and holds the line. The F self-lock then stops the lever from springing back and pushing the stopped load backwards. Size the bore from the catalog maximum load charts, drawn for a friction coefficient of 0.1.
