Genuine AirTAC heavy duty stopper cylinder, order code TTH80X40K from the TTH range. The options this code selects are decoded below; series data follow the official AirTAC catalog.
AirTAC built the TTH80X40K as the biggest stopper in the TTH heavy-duty series: a Dia 80 mm bore carrying the 40 mm stroke reserved for this size, with a lever roller riding on an adjustable oil shock absorber. At Dia 80 the cushion damping can be tuned in service, so the same stopper can be softened for light totes or firmed up for the heaviest pallets. Being single acting pull-in, air retracts the lever and the spring raises it the moment air is cut, so a supply failure leaves the conveyor blocked.
No lubrication is needed and the cylinder follows JIS standards. A threaded hole accepts a proximity sensor with an M8x1.0 thread, the size used on Dia 50 to Dia 80 bodies, and plumbing is fixed at ordering from M5x0.8, PT1/8 or PT1/4 ports. Operating pressure at this bore is 0.2 to 1.0 MPa with 1.5 MPa (215 psi) proof pressure.
| Order code | TTH80X40K |
|---|---|
| Product | Heavy duty Stopper Cylinder |
| Bore | Ø80 mm, 40 mm stroke |
| Stopper | Lever roller, adjustable oil cushion |
| Magnet | No magnet |
| Action | Single acting, spring extend |
|---|---|
| Mounting | Flange |
| Bore / stroke | Ø20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm |
| Port | M5×0.8 · PT1/8 · PT1/4 |
| Stopper types | Lever roller, fixed oil cushion, Lever roller, adjustable oil cushion |
| Fluid | Air (filtered by 40 µm element) |
| Operating pressure | 0.25-1.0 MPa on Ø20, 0.2-1.0 MPa on other bores |
| Proof pressure | 1.5 MPa (215 psi) |
| Temperature | -20 to +70 °C |
| Cushion | Bumper |
| Lubrication | Not required |
Source: AirTAC Products Catalog 2026A (PDF01-P0752..P0753), TTH series specifications and ordering code.
Pick this code over TTH80X40L when you want to tune the oil cushion instead of running the fixed setting; both use the same lever roller. Move to TTH80X40KF only if stopped loads must also be held against the lever springing back, and to TTH80X40SK if your PLC needs magnet-based position feedback. The 40 mm stroke is the only stroke offered on Dia 80, and the TTH action code here means single acting pull-in rather than the double acting TWH version.
AirtacDistr lists every TTH order code with its price on one page at https://airtacdistr.com/products/airtac-tth-heavy-duty-stopper-cylinder
Dia 80 is the largest TTH bore, sized for the heaviest pallet transfer lanes; the fail-safe spring keeps the stopper raised and the lane blocked whenever air pressure drops.
Stop and release incoming pallets one by one before a palletizer, with the adjustable oil cushion set to absorb the impact of fully loaded units.
Park workpieces in accumulation conveyor sections; the bumper cushion and impact-resistant thick piston rod take repeated stopping duty without external lubrication.
Dia 80 mm bore, 40 mm stroke, single acting spring-extend (pull-in) stopper with lever roller and adjustable oil cushion. Operating pressure 0.2 to 1.0 MPa, proof pressure 1.5 MPa (215 psi), temperature -20 to +70 C, port options M5x0.8, PT1/8 or PT1/4, sensor hole threaded M8x1.0, no lubrication required, no magnet fitted.
The cylinder is single acting pull-in: air holds the lever down, and when the air is cut the internal spring pushes the rod back up. The stopper therefore rises on air loss and keeps blocking the conveyor, a fail-safe behavior suited to pallet and tote lanes where an uncontrolled release would be unsafe.
