AirTAC TTH · Heavy duty Stopper Cylinder

Airtac TTH Stopper Cylinder TTH80X40KF

Genuine AirTAC heavy duty stopper cylinder, order code TTH80X40KF from the TTH range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • BoreØ80 mm, 40 mm stroke
  • StopperLever roller, adjustable oil cushion, self-lock
  • MagnetNo magnet
  • ActionSingle acting, spring extend
  • MountingFlange
  • Bore / strokeØ20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm
$421.04 $428.54Save 1%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every TTH bore, stopper and magnet on one page All TTH codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac TTH Stopper Cylinder TTH80X40KF

The TTH80X40KF pairs the largest TTH bore, Dia 80 mm with its 40 mm stroke, with two impact features at once: the lever roller on an adjustable oil shock absorber, and the F self-lock option. The self-lock stops the lever from springing back after it has been pressed, so the stopper cannot push the already-stopped load backwards, a real risk on accumulation lanes where boxes queue shoulder to shoulder.

Like every TTH stopper it is single acting pull-in: air retracts the rod and the spring raises it when air is cut, so a supply failure leaves the line blocked on the safe side. The Dia 80 body takes an M8x1.0 proximity sensor in its threaded hole, runs on 0.2 to 1.0 MPa with 1.5 MPa (215 psi) proof pressure across -20 to +70 C, and needs no lubrication.

Airtac TTH Stopper Cylinder TTH80X40KF Technical Specifications

Order codeTTH80X40KF
ProductHeavy duty Stopper Cylinder
BoreØ80 mm, 40 mm stroke
StopperLever roller, adjustable oil cushion, self-lock
MagnetNo magnet
ActionSingle acting, spring extend
MountingFlange
Bore / strokeØ20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm
PortM5×0.8 · PT1/8 · PT1/4
Stopper typesLever roller, fixed oil cushion, Lever roller, adjustable oil cushion
FluidAir (filtered by 40 µm element)
Operating pressure0.25-1.0 MPa on Ø20, 0.2-1.0 MPa on other bores
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
CushionBumper
LubricationNot required

Source: AirTAC Products Catalog 2026A (PDF01-P0752..P0753), TTH series specifications and ordering code.

How to choose

This code exists for one decision: whether the stopped load must be held against lever spring-back. Choose plain TTH80X40K when the load sits free in front of the stopper; choose TTH80X40KF when queues, gravity feed or downstream pushes could shove the part back at the lever. The self-lock is offered on the lever roller only, so it combines with K (adjustable cushion) or L (fixed cushion) but not with other stopper styles; add S (TTH80X40SKF) if magnet feedback is also required.

AirtacDistr lists every TTH order code with its price on one page at https://airtacdistr.com/products/airtac-tth-heavy-duty-stopper-cylinder

Applications

forklift

Pallet queue holding

On lanes where pallets are pushed together into a queue, the self-lock keeps the lever from rebounding and shoving the front pallet backwards out of position.

package_2

Case packing infeed

Stop cartons one at a time at a case packer; the adjustable oil cushion soaks up the impact while the self-lock stops the lever from nudging the stopped box off its pitch.

vertical_align_center

Gravity-fed accumulation

On slightly inclined gravity sections where parts drift against the stopper, the self-lock prevents the raised lever from throwing the load back up the slope.

FAQ

What are the key specifications of the TTH80X40KF?

Dia 80 mm bore, 40 mm stroke, single acting pull-in stopper with lever roller, adjustable oil cushion and self-lock (F option), no magnet. Operating pressure 0.2 to 1.0 MPa, proof pressure 1.5 MPa (215 psi), temperature -20 to +70 C, ports M5x0.8, PT1/8 or PT1/4, sensor hole M8x1.0, no lubrication needed.

What exactly does the self-lock option add?

It stops the lever from springing back once it has been depressed, so the stopper does not push the load it has just stopped backwards. It is available only with the lever roller stopper; the rest of the TTH80X40K behavior, including the spring-rise fail-safe when air is cut, is unchanged.
