AirTAC TTH · Heavy duty Stopper Cylinder

Airtac TTH Stopper Cylinder TTH80X40SK

Genuine AirTAC heavy duty stopper cylinder, order code TTH80X40SK from the TTH range. The options this code selects are decoded below; series data follow the official AirTAC catalog.

  • BoreØ80 mm, 40 mm stroke
  • StopperLever roller, adjustable oil cushion
  • MagnetMagnet
  • ActionSingle acting, spring extend
  • MountingFlange
  • Bore / strokeØ20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm
$435.00 $442.50Save 1%
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every TTH bore, stopper and magnet on one page All TTH codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac TTH Stopper Cylinder TTH80X40SK

The TTH80X40SK adds the S magnet option to the Dia 80 mm, 40 mm stroke TTH stopper, so a proximity switch can confirm rod position electrically instead of relying on timers. The piston carries a built-in magnet, and the Dia 50 to Dia 80 body provides the matching M8x1.0 threaded sensor hole, so wiring a position signal into the PLC is a direct fit without brackets or adapters.

Mechanically it is the same heavy-duty stopper: a lever roller on an adjustable oil shock absorber that can be tuned for the load, single acting pull-in action where air retracts and the spring raises the stopper on air loss, 0.2 to 1.0 MPa operating pressure with 1.5 MPa (215 psi) proof pressure, and no lubrication required.

Airtac TTH Stopper Cylinder TTH80X40SK Technical Specifications

Order codeTTH80X40SK
ProductHeavy duty Stopper Cylinder
BoreØ80 mm, 40 mm stroke
StopperLever roller, adjustable oil cushion
MagnetMagnet
ActionSingle acting, spring extend
MountingFlange
Bore / strokeØ20 15 mm · Ø25 15 mm · Ø32 20 mm · Ø40 30 mm · Ø50 30 mm · Ø63 30 mm · Ø80 40 mm
PortM5×0.8 · PT1/8 · PT1/4
Stopper typesLever roller, fixed oil cushion, Lever roller, adjustable oil cushion
FluidAir (filtered by 40 µm element)
Operating pressure0.25-1.0 MPa on Ø20, 0.2-1.0 MPa on other bores
Proof pressure1.5 MPa (215 psi)
Temperature-20 to +70 °C
CushionBumper
LubricationNot required

Source: AirTAC Products Catalog 2026A (PDF01-P0752..P0753), TTH series specifications and ordering code.

How to choose

Order TTH80X40SK instead of TTH80X40K when your controls need electrical confirmation of the stopper position; without the S option the piston carries no magnet and a sensor will not detect it. If you also need the lever held against spring-back, that combination is TTH80X40SKF. Compared with the L variant (TTH80X40SL), this K code gives you the adjustable oil cushion rather than the fixed setting. Note the magnet signals rod position only; it does not change the spring-extend safety behavior.

AirtacDistr lists every TTH order code with its price on one page at https://airtacdistr.com/products/airtac-tth-heavy-duty-stopper-cylinder

Applications

sensors

Automated sortation feedback

Use a proximity switch in the M8x1.0 sensor hole so the PLC verifies the stopper is actually down before releasing the next carton, closing the loop on every divert cycle.

conveyor_belt

Pallet transfer handoff

Coordinate stopper down and up signals with downstream transfer equipment on heavy pallet lines, using the magnet feedback instead of optimistic timing.

settings

Machine condition monitoring

Log stopper cycles from the magnetic position signal to spot sticking or mis-stops early on critical Dia 80 lanes, where the adjustable cushion can then be retuned for the load.

FAQ

What are the key specifications of the TTH80X40SK?

Dia 80 mm bore, 40 mm stroke, single acting pull-in stopper with lever roller and adjustable oil cushion, built-in piston magnet (S option). Operating pressure 0.2 to 1.0 MPa, proof pressure 1.5 MPa (215 psi), temperature -20 to +70 C, ports M5x0.8, PT1/8 or PT1/4, sensor hole M8x1.0, no lubrication required, no self-lock.

How do I pick the sensor for this magnet version?

Use a proximity sensor sized for the threaded hole in the body; on Dia 50 to Dia 80 TTH stoppers, which includes this Dia 80 model, that hole is M8x1.0. Confirm the sensing distance and switching type from the datasheet of the switch you plan to mount.
