AirTAC 4V Series · 5/2-way Solenoid Valve

Airtac 4V300 Solenoid Valve 4V320-10-A

The AirTAC 4V300 Solenoid Valve 4V320-10-A is a genuine 5/2-way double solenoid (memory) solenoid valve with PT3/8 ports and an effective area of 28.0 mm² (Cv 1.65). It is an internally piloted spool valve that directs compressed air to double-acting cylinders and actuators.

  • Valve type5/2-way
  • FunctionDouble solenoid (memory)
  • Port sizePT3/8
  • Effective area28.0 mm²
  • Flow (Cv)1.65
  • Series4V300
$58.12 $65.62Save 11% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every 4V320-10 stroke, mounting and version on one page All 4V320-10 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac 4V300 Solenoid Valve 4V320-10-A

The AirTAC 4V320-10A is a 5/2-way double-solenoid pneumatic directional valve built on the 4V300 body platform. It directs compressed air to double-acting cylinders and actuators using a memory-spool design: a brief pulse to coil 14 shifts the spool to one position, and a pulse to coil 12 shifts it back. When power is removed from both coils the spool stays in its last-commanded position—held by land friction and balanced pressure, with no spring and no holding current—so the actuator holds its state even if the electrical signal is lost.

This AC220V terminal-box model weighs 400 g and delivers an effective area of 28.0 mm2 (Cv 1.65), suiting ~O50-80 mm bore cylinders in general industrial service. The 4.5 VA coil operates on 50/60 Hz mains, and the aluminum-alloy body carries an IP65 protection rating. Response time is 0.05 s or below, and the valve can be manifold-mounted for multi-station automation.

Airtac 4V300 Solenoid Valve 4V320-10-A Technical Specifications

ModelAirtac 4V300 Solenoid Valve 4V320-10-A
Series4V300 solenoid valve (spool type)
Valve type5/2-way
FunctionDouble solenoid (memory)
Port sizePT3/8
Exhaust portPT1/4
Effective area (Cv)28.0 mm² (Cv 1.65)
FluidAir (filtered by 40µm element)
Pilot typeInternal / external pilot
Operating pressure0.15 – 0.8 MPa
Proof pressure1.2 MPa
Max frequency4 cycle/sec
Response time≤ 0.05 s (activating)
Temperature-20 to +70 °C
Body materialAluminum alloy
Weight400 g

Specifications follow the official AirTAC 4V series datasheet. Lubrication not required. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.

Flow & Coil Options

Effective area28.0 mm²
Flow coefficientCv 1.65
Response time≤ 0.05 s
Coil powerAC 4.5 VA · DC24V 3.0 W · DC12V 2.5 W
Protection / insulationIP65 (DIN40050), B-class
Voltage optionsDC24V, DC12V, AC110V, AC220V
Manual overrideYes (locking / non-locking)

Size the valve so effective area / Cv is not the bottleneck for your cylinder bore and speed. Undersized valves slow the actuator. Note 5/3 (center) versions have a smaller effective area than the 5/2 of the same body size.

Model Code: Airtac 4V300 Solenoid Valve 4V320-10-A

4VSolenoid valve, spool type, 4-series.
3Body size (4V300) — sets port & flow.
2Function: 1 = single 5/2, 2 = double 5/2, 3 = 5/3.
-10Port thread: M5 / 06=1/8" / 08=1/4" / 10=3/8" / 15=1/2".

Related: 4V310 (single), 4V320 (double), 4V330C/E/P (5/3 center). Add the voltage suffix when ordering.

Where the Airtac 4V300 Solenoid Valve 4V320-10-A Is Used

conveyor_belt

Material-Handling Gates & Diverters

The memory spool holds a diverter gate in its last position even if a panel E-stop drops control power, preventing unintended product routing on conveyors and sortation systems.

precision_manufacturing

Clamp & Fixture Circuits

Pulse the 4V320-10A to clamp a part, then remove the signal. The valve stays shifted, keeping the clamp engaged while the machine performs a cycle, and a second pulse releases it.

factory

Large-Bore Cylinder Actuation

With a Cv of 1.65, this valve provides the flow needed to cycle ~O63-80 mm double-acting cylinders at production speed on presses, bending machines, and assembly stations.

Is the Airtac 4V300 Solenoid Valve 4V320-10-A the Right Valve?

Choose the 4V320-10A when you need a 5/2 double-solenoid valve that holds its last position on power loss without a spring return. Its 28.0 mm2 effective area (Cv 1.65) fits ~O50-80 mm double-acting cylinders; step down to a 4V200-series valve (Cv 1.0) for smaller bores, or move up to the 4V400 (Cv 2.82) for larger actuators. The double-solenoid memory function is ideal where a constant electrical signal is impractical or where the valve must survive a control-power interruption without shifting.

For a direct replacement, match five points: body size (4V300), function (20 = double solenoid 5/2), port and thread (3/8 in PT), coil voltage (AC220V), and electrical entry (terminal box). If your application needs a spring-return action, use the single-solenoid 4V310 instead. The 4V320 also accepts a common sub-base manifold, letting you gang multiple valves with a shared pressure supply and collective exhaust.

AirtacDistr lists every 4V320-10 order code with its price on one page at https://airtacdistr.com/products/airtac-4v320-10-solenoid-valve

Quick checklist

  • ✓ Required flow (Cv) for cylinder & speed
  • ✓ Function: single / double / 5-3 center
  • ✓ Coil voltage (DC24 / AC220 …)
  • ✓ Port thread (M5 / 1/8 / 1/4 / 3/8 / 1/2)
  • ✓ Single valve or manifold base?
Ask an Engineer

Installation & Wiring Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 0.8 MPa operating pressure.
  • check Match coil voltage to your controller output.
  • check Use the manual override to test before powering.
  • check Fit silencers or fittings to the exhaust ports.
  • check Wiring by qualified personnel per AirTAC docs.

Airtac 4V300 Solenoid Valve 4V320-10-A FAQ

Its 28.0 mm2 effective area (Cv 1.65) suits double-acting cylinders in the ~O50-80 mm range for typical industrial cycle rates. For smaller bores a 4V200 valve may be more economical; for larger bores consider the 4V400 series.

A short pulse to one coil shifts the spool; it stays there by land friction and balanced pressure after the pulse ends, with no spring and no holding current. It is not a magnetic latch. For suspended or vertical loads that must not drift, add a pilot-operated check valve or mechanical brake at the cylinder ports—do not rely on the valve alone as a safety hold.
