AirTAC 4V Series · 5/3-way Solenoid Valve

Airtac 4V300 Solenoid Valve 4V330E-10-A

The AirTAC 4V300 Solenoid Valve 4V330E-10-A is a genuine 5/3-way 5/3 double solenoid — exhaust center solenoid valve with PT3/8 ports and an effective area of 21.3 mm² (Cv 1.25). It is an internally piloted spool valve that directs compressed air to double-acting cylinders and actuators.

  • Valve type5/3-way
  • Function5/3 double solenoid — Exhaust center
  • Port sizePT3/8
  • Effective area21.3 mm²
  • Flow (Cv)1.25
  • Series4V300
$67.43 $74.93Save 10% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every 4V330E-10 stroke, mounting and version on one page All 4V330E-10 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac 4V300 Solenoid Valve 4V330E-10-A

The AirTAC 4V330E-10A is a 5/3-way double-solenoid pneumatic directional valve built on the 4V300 body, directing compressed air to double-acting cylinders and rotary actuators. Its exhaust center configuration means that when both solenoids are de-energized, the cylinder ports A and B are connected to exhaust—allowing the cylinder to float freely. This makes it the go-to choice for manual positioning, operator-adjusted strokes, or any application where the load must not be pneumatically locked at mid-stroke.

With a 3/8-inch PT port and an AC220V coil drawing 4.5 VA, this valve suits mid-bore cylinders in the ~50–80 mm range. It delivers an effective area of 21.3 mm² (Cv 1.25, catalog figure for the 4V330C-10) and a maximum cycling speed of 3 cycles per second, with a response time of 0.05 seconds or less. The IP65-rated aluminum body, integrated manual override, and compatibility with manifold bases make it a rugged, flexible solution for machine builders.

Airtac 4V300 Solenoid Valve 4V330E-10-A Technical Specifications

ModelAirtac 4V300 Solenoid Valve 4V330E-10-A
Series4V300 solenoid valve (spool type)
Valve type5/3-way
Function5/3 double solenoid — Exhaust center
Port sizePT3/8
Exhaust portPT1/4
Effective area (Cv)21.3 mm² (Cv 1.25)
FluidAir (filtered by 40µm element)
Pilot typeInternal / external pilot
Operating pressure0.15 – 0.8 MPa
Proof pressure1.2 MPa
Max frequency3 cycle/sec
Response time≤ 0.05 s (activating)
Temperature-20 to +70 °C
Body materialAluminum alloy
Weight450 g

Specifications follow the official AirTAC 4V series datasheet. Lubrication not required. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.

Flow & Coil Options

Effective area21.3 mm²
Flow coefficientCv 1.25
Response time≤ 0.05 s
Coil powerAC 4.5 VA · DC24V 3.0 W · DC12V 2.5 W
Protection / insulationIP65 (DIN40050), B-class
Voltage optionsDC24V, DC12V, AC110V, AC220V
Manual overrideYes (locking / non-locking)

Size the valve so effective area / Cv is not the bottleneck for your cylinder bore and speed. Undersized valves slow the actuator. Note 5/3 (center) versions have a smaller effective area than the 5/2 of the same body size.

Model Code: Airtac 4V300 Solenoid Valve 4V330E-10-A

4VSolenoid valve, spool type, 4-series.
3Body size (4V300) — sets port & flow.
3Function: 1 = single 5/2, 2 = double 5/2, 3 = 5/3.
-10Port thread: M5 / 06=1/8" / 08=1/4" / 10=3/8" / 15=1/2".

Related: 4V310 (single), 4V320 (double), 4V330C/E/P (5/3 center). Add the voltage suffix when ordering.

Where the Airtac 4V300 Solenoid Valve 4V330E-10-A Is Used

handyman

Manual Positioning Stations

The exhaust center allows operators to manually slide a cylinder rod or adjust a fixture by hand when the valve is at rest, making it perfect for assembly jigs and operator-guided alignment tools.

conveyor_belt

Material Handling & Sorting

Drives double-acting diverters and pushers on conveyor lines. The float condition at center prevents trapped pressure from causing unintended movement during a machine stop or emergency halt.

precision_manufacturing

Clamping with Manual Unload

Used in clamping circuits where the clamp must release completely and float free upon de-energizing, allowing a part to be removed without any residual pneumatic force holding it in place.

Is the Airtac 4V300 Solenoid Valve 4V330E-10-A the Right Valve?

Choose the 4V330E-10A when your pneumatic circuit needs a 5/3 exhaust center function on a 3/8-inch port. The exhaust center is ideal for applications where the cylinder must be manually moved or where holding position is undesirable at idle. If you need the cylinder to lock in place at center, step to the 4V330C (closed center); if you require both sides pressurized at center, select the 4V330P (pressure center).

For replacement, match all five points: the 4V300 body size, the 5/3 exhaust-center function, the 3/8-inch PT port, the AC220V coil voltage, and the terminal-box electrical entry. If your cylinder is smaller (below ~40 mm bore), the 4V200 series (Cv 1.0) may be a better fit; for larger bores above 80 mm, consider the 4V400 with its higher Cv of 2.82. This valve can be used standalone or on a common manifold with other 4V300 units.

AirtacDistr lists every 4V330E-10 order code with its price on one page at https://airtacdistr.com/products/airtac-4v330e-10-solenoid-valve

Quick checklist

  • ✓ Required flow (Cv) for cylinder & speed
  • ✓ Function: single / double / 5-3 center
  • ✓ Coil voltage (DC24 / AC220 …)
  • ✓ Port thread (M5 / 1/8 / 1/4 / 3/8 / 1/2)
  • ✓ Single valve or manifold base?
Ask an Engineer

Installation & Wiring Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 0.8 MPa operating pressure.
  • check Match coil voltage to your controller output.
  • check Use the manual override to test before powering.
  • check Fit silencers or fittings to the exhaust ports.
  • check Wiring by qualified personnel per AirTAC docs.

Airtac 4V300 Solenoid Valve 4V330E-10-A FAQ

In the de-energized center position, both cylinder ports (A and B) are connected to exhaust while the inlet port is blocked. This means no compressed air is trapped in the cylinder, allowing the piston rod to be moved freely by an external force. It is the correct choice when you need a cylinder to float rather than hold position.

With an effective area of 21.3 mm² (Cv 1.25, catalog figure for the 4V330C-10), the 4V330E-10A suits double-acting cylinders with bores approximately in the 50–80 mm range for typical industrial cycle rates. For precise sizing, always match the valve's Cv to the cylinder's swept volume and required speed.
