The AirTAC 4V400 Solenoid Valve 4V420-15-A is a genuine 5/2-way double solenoid (memory) solenoid valve with PT1/2 ports and an effective area of 48.0 mm² (Cv 2.82). It is an internally piloted spool valve that directs compressed air to double-acting cylinders and actuators.
The AirTAC 4V420-15A is a 5/2-way double-solenoid pneumatic valve that directs compressed air to double-acting cylinders and rotary actuators. Its memory function means the spool stays in its last pulsed position when power is removed—no spring return and no holding current required. This AC220V model uses a 4.5 VA coil and connects through a standard terminal box.
Built on the largest 4V body, it delivers an effective area of 48.0 mm² (Cv 2.82), making it a strong match for bore sizes around Ø80–125 mm. The sliding-column design responds in 0.05 s or less and needs no lubrication, while the aluminum-alloy body keeps weight to 720 g. IP65 protection and a manual override are standard.
| Model | Airtac 4V400 Solenoid Valve 4V420-15-A |
|---|---|
| Series | 4V400 solenoid valve (spool type) |
| Valve type | 5/2-way |
| Function | Double solenoid (memory) |
| Port size | PT1/2 |
| Exhaust port | PT1/2 |
| Effective area (Cv) | 48.0 mm² (Cv 2.82) |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Pilot type | Internal / external pilot |
| Operating pressure | 0.15 – 0.8 MPa |
| Proof pressure | 1.2 MPa |
| Max frequency | 3 cycle/sec |
| Response time | ≤ 0.05 s (activating) |
| Temperature | -20 to +70 °C |
| Body material | Aluminum alloy |
| Weight | 720 g |
Specifications follow the official AirTAC 4V series datasheet. Lubrication not required. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
| Effective area | 48.0 mm² |
|---|---|
| Flow coefficient | Cv 2.82 |
| Response time | ≤ 0.05 s |
| Coil power | AC 4.5 VA · DC24V 3.0 W · DC12V 2.5 W |
| Protection / insulation | IP65 (DIN40050), B-class |
| Voltage options | DC24V, DC12V, AC110V, AC220V |
| Manual override | Yes (locking / non-locking) |
Size the valve so effective area / Cv is not the bottleneck for your cylinder bore and speed. Undersized valves slow the actuator. Note 5/3 (center) versions have a smaller effective area than the 5/2 of the same body size.
| 4V | Solenoid valve, spool type, 4-series. |
|---|---|
| 4 | Body size (4V400) — sets port & flow. |
| 2 | Function: 1 = single 5/2, 2 = double 5/2, 3 = 5/3. |
| -15 | Port thread: M5 / 06=1/8" / 08=1/4" / 10=3/8" / 15=1/2". |
Related: 4V410 (single), 4V420 (double), 4V430C/E/P (5/3 center). Add the voltage suffix when ordering.
Drives a heavy-duty double-acting cylinder that pushes finished parts off a conveyor. The memory spool holds the cylinder retracted during a power sag, preventing a mid-cycle crash.
Pulses to extend a large-bore clamp, then holds clamping force with both coils de-energized. Ideal for woodworking or welding fixtures where constant power isn't practical.
Controls the reciprocating motion of a strip feeder on a stamping press. The 4V420-15A's 3 cycles/sec max frequency and 0.05 s response keep the feed in step with the press ram.
Choose the 4V420-15A when your application needs a 5/2 valve that must hold its last state after a power-off or emergency stop—the dual-coil memory spool eliminates the need for a continuous electrical signal. If your cylinder is smaller (around Ø50–63 mm), stepping down to a 4V300 series (Cv 1.65) often gives a better response-to-flow match. For flow beyond this 1/2-inch body, consider a larger valve series or a manifold group.
When replacing an existing valve, match five points: body size (4V400), function (double 5/2), port and thread (1/2-inch PT), coil voltage (AC220V), and electrical entry (terminal box). This ensures direct compatibility without re-plumbing or rewiring.
AirtacDistr lists every 4V420-15 order code with its price on one page at https://airtacdistr.com/products/airtac-4v420-15-solenoid-valve
Quick checklist
The 4V420-15A is a double-solenoid memory valve. Its spool remains in the position it was last pulsed to, held by friction and balanced pressure. The cylinder will stay put—it will not spring back. This is not a safety-rated hold, so if you are suspending a load, add a pilot-operated check valve or mechanical brake at the cylinder ports.
With a Cv of 2.82 (48.0 mm² effective area), it suits double-acting cylinders roughly in the Ø80–125 mm bore range. Smaller cylinders will cycle faster than needed, while much larger ones may feel sluggish. Always size based on your required force, speed, and operating pressure (0.15–0.8 MPa).
