The AirTAC B01-SDAD Dedicated Cylinder B01-SDAD32X60 is a genuine double-acting COMPACT cylinder with a piston rod out BOTH ends (Ø32mm bore, 60mm stroke). The through-rod resists twisting and lets you drive a tool on one end while a switch or dog reads position on the other — with identical force in both directions.
The B01-SDAD32X60 is a double-acting, double-rod compact cylinder. The B01- prefix marks this as AirTAC's application-dedicated (customer-specified) line of the base SDAD32X60, meaning it is mechanically identical to the standard model. Because a 12 mm rod exits both ends of the riveted body, the annular piston area is identical in each chamber, ensuring push force equals pull force at 345.6 N for 0.5 MPa. This symmetric output is ideal for balancing loads without tweaking regulator pressures.
The through-rod geometry inherently resists twisting, allowing you to mount a work tool on one end and a dog or switch on the opposite side. With a 60 mm stroke and PT1/8 port, the short body saves axial mounting depth where larger profile cylinders cannot fit. End-of-stroke deceleration relies on a fixed NBR bumper rather than an adjustable air cushion, and this specific SKU lacks a piston magnet, so it cannot directly host magnetic switches.
| Model | Airtac B01-SDAD Dedicated Cylinder B01-SDAD32X60 |
|---|---|
| Series | SDAD compact double-rod cylinder |
| Bore size | Ø32 mm |
| Stroke | 60 mm |
| Acting type | Double acting, rod both ends |
| Port size | PT1/8 |
| Rod end thread | M6×1.0 female / M10×1.25 male (B) |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
| Max standard stroke | Up to 120 mm |
Because a rod occupies both cylinder chambers, the effective area — and therefore the force — is identical in both directions. Specifications follow the official AirTAC SDAD datasheet.
| Pressure | Force (both directions) |
|---|---|
| 0.5 MPa | 346 N |
| 0.7 MPa | 484 N |
| Max (@1.0 MPa) | 70 kgf |
Force uses the annular (rod-side) area on both strokes, so extend and retract match. Actual usable force is lower than theoretical due to friction. Size with a safety margin.
| SDAD | Compact double-acting cylinder, rod out both ends. |
|---|---|
| 32 | Bore size in mm. |
| ×60 | Stroke length in mm. |
| S | Built-in magnet for magnetic-switch sensing (omit = none). |
| B | Male-thread piston rods (omit = female thread). |
Thread: PT standard. Related SDA-family variants: SDA (single rod), SSA/STA (single acting), SDAJ (adjustable stroke), SDAT (duplex), SDAW (duplex-end).
Drives a parts ejector on one rod end while the opposite end pushes a counterweight, utilizing the 345.6 N equal force to keep the ejection motion perfectly balanced.
Transfers workpieces between two parallel conveyor lanes simultaneously using both rod ends, relying on the through-rod anti-rotation property to prevent jaw binding.
Fits into a 60 mm stroke riveted body to press pins in tight assembly fixtures, using the fixed NBR bumper to absorb the end shock without requiring extra cushion valves.
When sizing this 32 mm bore, compare its 345.6 N output at 0.5 MPa against adjacent options. Dropping down to SDAD25 yields 206.2 N, whereas stepping up to SDAD40 provides 527.8 N. This B01-SDAD32X60 configuration features a 60 mm stroke, female M6x1.0 rod threads on both ends, and no magnet (S option absent).
The dual-end through-rod prevents rotation and enables dual-end tooling, but remember that a plain cylinder drifts when air is lost or the valve centers. The fixed NBR bumper only decelerates the stroke end; it does not lock the piston. For load holding without live pressure, integrate an external rod lock or a pilot-operated check valve into your pneumatic circuit.
Quick checklist
Because the double-rod design yields equal annular areas, force is identical in both directions: 345.6 N at 0.5 MPa, 483.8 N at 0.7 MPa, and a theoretical maximum of 70 kgf at 1.0 MPa.
The B01- prefix denotes AirTAC's application-dedicated (customer-specified) variant of the SDAD32X60, sharing all physical specs with the base model. This specific SKU lacks a piston magnet, so it cannot host reed or electronic switches; you would need the -S variant for sensing.
