AirTAC SAI Series · ISO 15552 Cylinder

Airtac SAID63 Double Rod Cylinder SAID63X105

The AirTAC SAID63 Double Rod Cylinder SAID63X105 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø63mm bore and 105mm stroke, G3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ63 mm
  • Stroke105 mm
  • Port sizeG3/8
  • Acting typeDouble acting
  • Rod threadM16×1.5
  • CushionAdjustable, 36 mm
$105.37 $112.87Save 6% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SAID63 stroke, mounting and version on one page All SAID63 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SAID63 Double Rod Cylinder SAID63X105

The AirTAC SAID63X105 is a double-acting, double-rod ISO 15552 profile cylinder featuring a 63mm bore and a 105mm made-to-order stroke. Because a carbon steel rod exits both end covers, the annulus area is identical on both sides, yielding equal push and pull forces of 1402N at 0.5MPa. This twin-rod architecture provides inherent anti-rotation guidance for the payload.

The rear rod extension allows you to mount a cam or position flag directly opposite the primary workpiece, enabling dual-side sensing without external mechanisms. It shares the standard extruded aluminum barrel with sensor grooves on both sides, though PT tapered ports and adjustable air cushions are fitted at both ends to manage kinetic energy.

Airtac SAID63 Double Rod Cylinder SAID63X105 Technical Specifications

ModelAirtac SAID63 Double Rod Cylinder SAID63X105
SeriesSAI ISO 15552 profile cylinder
Bore sizeØ63 mm
Stroke105 mm
Acting typeDouble acting
Port sizeG3/8
Rod threadM16×1.5
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 800 mm/s
CushionAdjustable, 36 mm
Max strokeUp to 1500 mm

Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.

Theoretical Output Force (Ø63mm)

PressurePush forcePull force
0.5 MPa1402 N1402 N
0.7 MPa1962 N—
Max (@1.0 MPa)286 kgf

Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SAID63 Double Rod Cylinder SAID63X105

SAIISO 15552 profile-barrel cylinder series.
63Bore size in mm.
×105Stroke length in mm.
-SOptional built-in magnet for sensor position sensing.

Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.

Where the Airtac SAID63 Double Rod Cylinder SAID63X105 Is Used

sync_alt

Symmetric Force Transfer

Drives shuttles or indexing mechanisms where the 1402N push and pull forces must be perfectly matched to maintain consistent cycle times in both directions.

straighten

Anti-Rotation Slides

The twin carbon steel rods prevent piston rotation, providing precise linear guidance for lifting presses or tooling platforms that cannot tolerate angular drift.

settings_input_component

Rear-Rod Sensing

Utilize the protruding rear rod end to mount a physical limit flag or secondary cam, operating machinery safety gates independently of the primary front-side work tool.

Is the Airtac SAID63 Double Rod Cylinder SAID63X105 the Right Cylinder?

Select this 63mm bore over the smaller 50mm option (which provides 825N each way at 0.5MPa) when your application demands over 1400N of symmetric force, or step up to the 80mm bore (2268N) for heavier transfer loads. The 105mm stroke is non-standard and made-to-order; ensure you have the exact rear-rod clearance required, as the overall length exceeds a standard single-rod SAI cylinder. Mounting options include the SAID-specific set of Basic, FA, LB, TC, FTC, TCM1, and TCM2.

Remember that the adjustable air cushions only decelerate the piston near stroke end; they do not hold the load. If your system loses air pressure, the piston will drift, so you would need an external pilot-operated check valve or a related BSAID clamp-lock cylinder for true position holding. Being dimensionally interchangeable per ISO 15552, it serves as a direct replacement for other ISO 15552 double-rod cylinders.

AirtacDistr lists every SAID63 order code with its price on one page at https://airtacdistr.com/products/airtac-said63-double-rod-iso-cylinder

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/NPT/G)
  • ✓ Magnet (-S) for sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SAID63 Double Rod Cylinder SAID63X105 FAQ

Because it is a double-rod cylinder, the effective piston area is the same on both sides. It delivers an equal 1402N of force in both extend and retract directions at 0.5MPa, and 1962N at 0.7MPa.

Yes, it is dimensionally interchangeable with ISO 15552 profile cylinders. However, the SAID series uses a reduced mounting set: Basic, FA, LB, TC, FTC, TCM1, and TCM2. It omits the FB, CA, CB, and CR mounts found on single-rod variants.
