AirTAC SAI Series · ISO 15552 Cylinder

Airtac SAID63 Double Rod Cylinder SAID63X140

The AirTAC SAID63 Double Rod Cylinder SAID63X140 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø63mm bore and 140mm stroke, G3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ63 mm
  • Stroke140 mm
  • Port sizeG3/8
  • Acting typeDouble acting
  • Rod threadM16×1.5
  • CushionAdjustable, 36 mm
$108.16 $115.66Save 6% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SAID63 stroke, mounting and version on one page All SAID63 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SAID63 Double Rod Cylinder SAID63X140

The AirTAC SAID63X140 is a double-acting, double-rod ISO 15552 profile cylinder featuring a 63mm bore and 140mm stroke. Because a carbon steel rod exits both end covers, the effective annulus area is identical in both directions, yielding exactly 1402 N of force at 0.5 MPa on extend and retract. The extruded aluminum barrel includes sensor grooves on both sides for flexible switch mounting.\n\nThis through-rod design is ideal when you need to mount the primary workpiece on one end and a secondary cam, position flag, or limit mechanism on the opposite rear rod end. It provides superior anti-rotation guidance compared to a single-rod SAI, while utilizing the standard PT tapered G3/8 porting and adjustable air cushions at both ends to decelerate the load smoothly.

Airtac SAID63 Double Rod Cylinder SAID63X140 Technical Specifications

ModelAirtac SAID63 Double Rod Cylinder SAID63X140
SeriesSAI ISO 15552 profile cylinder
Bore sizeØ63 mm
Stroke140 mm
Acting typeDouble acting
Port sizeG3/8
Rod threadM16×1.5
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 800 mm/s
CushionAdjustable, 36 mm
Max strokeUp to 1500 mm

Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.

Theoretical Output Force (Ø63mm)

PressurePush forcePull force
0.5 MPa1402 N1402 N
0.7 MPa1962 N—
Max (@1.0 MPa)286 kgf

Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SAID63 Double Rod Cylinder SAID63X140

SAIISO 15552 profile-barrel cylinder series.
63Bore size in mm.
×140Stroke length in mm.
-SOptional built-in magnet for sensor position sensing.

Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.

Where the Airtac SAID63 Double Rod Cylinder SAID63X140 Is Used

sync_alt

Symmetric Force Transfer

Drives dual-station mechanisms where the 1402 N output must remain perfectly balanced in both directions without relying on external flow controls.

straighten

Anti-Rotation Slides

The twin carbon steel rods guide the load rigidly against torsional twist, keeping precision tooling perfectly aligned throughout the 140mm travel.

settings_input_component

Rear-Rod Cam Actuation

Mount the primary tool on the front rod end and use the protruding rear rod end to trigger external mechanical limit valves or secondary mechanisms.

Is the Airtac SAID63 Double Rod Cylinder SAID63X140 the Right Cylinder?

Choose this 63mm bore when you need balanced bidirectional power and higher side-load stability than smaller variants offer. If your application requires less force, the 50mm bore neighbor provides 825 N each way at 0.5 MPa; if you need more push, step up to the 80mm bore for 2268 N. The twin-rod architecture is specifically selected over a single-rod cylinder when dual-side actuation or strict anti-rotation guidance is required.\n\nAs a true ISO 15552 profile cylinder, it serves as a direct replacement for other ISO 15552 double-rod cylinders using standard mounting accessories (Basic, FA, LB, TC, FTC, TCM1, TCM2). Note that a plain SAID does not hold its position if air pressure is lost; for load-holding safety, consider the SAIL or BSAID series. Because this is a non-magnet version, position sensing requires external contact limits rather than internal CMSE or DMSE switches.

AirtacDistr lists every SAID63 order code with its price on one page at https://airtacdistr.com/products/airtac-said63-double-rod-iso-cylinder

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/NPT/G)
  • ✓ Magnet (-S) for sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SAID63 Double Rod Cylinder SAID63X140 FAQ

Because it is a double-rod cylinder, the rod area is subtracted from both sides of the piston, making extend and retract forces equal. It delivers 1402 N at 0.5 MPa, 1962 N at 0.7 MPa, and 2523 N at 0.9 MPa in both directions.

Yes, the SAID63X140 is dimensionally interchangeable per ISO 15552 and uses the standard profile mounting interface. It omits certain single-rod mounts (FB, CA, CB, CR) but supports the common SAID accessory set including Basic, FA, LB, TC, FTC, TCM1, and TCM2.
