AirTAC SAI Series · ISO 15552 Cylinder

Airtac SAID63 Double Rod Cylinder SAID63X15

The AirTAC SAID63 Double Rod Cylinder SAID63X15 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø63mm bore and 15mm stroke, G3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ63 mm
  • Stroke15 mm
  • Port sizeG3/8
  • Acting typeDouble acting
  • Rod threadM16×1.5
  • CushionAdjustable, 36 mm
$93.28 $100.78Save 7% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SAID63 stroke, mounting and version on one page All SAID63 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SAID63 Double Rod Cylinder SAID63X15

The AirTAC SAID63X15 is a double-acting, double-rod ISO 15552 profile cylinder engineered for compact, symmetric actuation. Because the piston rod exits both end covers, the effective annulus area is identical on extend and retract, yielding an equal force of 1402 N and matched speed in both directions at 0.5 MPa.

This 15 mm stroke variant is a non-standard, made-to-order configuration tailored for extremely short strokes. The carbon steel rod provides robust axial strength, while the extruded aluminum barrel features dual sensor grooves. Without a magnet specified, it operates mechanically, though the twin-rod design inherently resists load rotation better than a single-rod SAI.

Airtac SAID63 Double Rod Cylinder SAID63X15 Technical Specifications

ModelAirtac SAID63 Double Rod Cylinder SAID63X15
SeriesSAI ISO 15552 profile cylinder
Bore sizeØ63 mm
Stroke15 mm
Acting typeDouble acting
Port sizeG3/8
Rod threadM16×1.5
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 800 mm/s
CushionAdjustable, 36 mm
Max strokeUp to 1500 mm

Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.

Theoretical Output Force (Ø63mm)

PressurePush forcePull force
0.5 MPa1402 N1402 N
0.7 MPa1962 N—
Max (@1.0 MPa)286 kgf

Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SAID63 Double Rod Cylinder SAID63X15

SAIISO 15552 profile-barrel cylinder series.
63Bore size in mm.
×15Stroke length in mm.
-SOptional built-in magnet for sensor position sensing.

Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.

Where the Airtac SAID63 Double Rod Cylinder SAID63X15 Is Used

sync_alt

Twin-Station Actuation

Drives two synchronized workpieces from a single piston, utilizing the equal 1402 N force on both the front and rear rod ends for balanced, compact transfer.

straighten

Anti-Rotation Guidance

The dual-rod geometry inherently resists torsional rotation, providing stable guidance for short-stroke 15 mm clamping or positioning tasks without external guides.

settings_input_component

Rear-Cam Triggering

Mounts a cam or mechanical flag on the rear rod end to actuate external limit switches, leveraging the short stroke for high-cycle sequencing.

Is the Airtac SAID63 Double Rod Cylinder SAID63X15 the Right Cylinder?

Select this 63 mm bore cylinder when an application demands exactly 1402 N of push and pull force within a 15 mm stroke envelope. If your project requires less force, stepping down to the 50 mm bore yields 825 N both ways; stepping up to the 80 mm bore provides 2268 N. The SAID series is chosen over a single-rod SAI when the rear rod end is needed to mount a cam, a position flag, or drive a secondary mechanism.

For direct compatibility, this cylinder uses a PT tapered G3/8 port and supports ISO 15552 mounting accessories (Basic, FA, LB, TC, FTC, TCM1, TCM2). Note that the adjustable air cushions at both ends only decelerate the piston near stroke end; they do not hold the load. If position holding without live air pressure is required, consider an external pilot-operated check valve or the BSAID clamp-lock variant.

AirtacDistr lists every SAID63 order code with its price on one page at https://airtacdistr.com/products/airtac-said63-double-rod-iso-cylinder

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/NPT/G)
  • ✓ Magnet (-S) for sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SAID63 Double Rod Cylinder SAID63X15 FAQ

The SAID63X15 provides equal force in both extend and retract directions due to its double-rod design. It outputs 1402 N at 0.5 MPa, 1962 N at 0.7 MPa, and 2523 N at 0.9 MPa.

Yes, the SAID63X15 is dimensionally interchangeable per ISO 15552. It uses standard mounting interfaces like TC and LB, but note the 15 mm stroke is a non-standard, made-to-order length.
