AirTAC SAI Series · ISO 15552 Cylinder

Airtac SAIJ40 Adjustable Cylinder SAIJ40X10-10

The AirTAC SAIJ40 Adjustable Cylinder SAIJ40X10-10 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø40mm bore and 10mm stroke, G1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ40 mm
  • Stroke10 mm
  • Port sizeG1/4
  • Acting typeDouble acting
  • Rod threadM12×1.25
  • CushionAdjustable, 30 mm
$64.17 $71.67Save 10% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SAIJ40 stroke, mounting and version on one page All SAIJ40 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SAIJ40 Adjustable Cylinder SAIJ40X10-10

The AirTAC SAIJ40X10-10 is a double-acting ISO 15552 profile cylinder featuring a rear-mounted stroke adjuster. It provides a usable travel window of 0-10mm, allowing you to dial back the 10mm nominal stroke precisely to zero during commissioning.

This bore 40 unit uses a PT tapered G1/4 port and a 16mm carbon steel rod with an M12x1.25 thread. The rear adjuster functions strictly as a mechanical stop for end-position tuning; it does not hold the load without live air. For true load-holding without pressure, consider the SAIL or BSAI series instead.

Airtac SAIJ40 Adjustable Cylinder SAIJ40X10-10 Technical Specifications

ModelAirtac SAIJ40 Adjustable Cylinder SAIJ40X10-10
SeriesSAI ISO 15552 profile cylinder
Bore sizeØ40 mm
Stroke10 mm
Acting typeDouble acting
Port sizeG1/4
Rod threadM12×1.25
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 800 mm/s
CushionAdjustable, 30 mm
Max strokeUp to 1200 mm

Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.

Theoretical Output Force (Ø40mm)

PressurePush forcePull force
0.5 MPa528 N528 N
0.7 MPa739 N—
Max (@1.0 MPa)108 kgf

Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SAIJ40 Adjustable Cylinder SAIJ40X10-10

SAIISO 15552 profile-barrel cylinder series.
40Bore size in mm.
×10Stroke length in mm.
-SOptional built-in magnet for sensor position sensing.

Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.

Where the Airtac SAIJ40 Adjustable Cylinder SAIJ40X10-10 Is Used

tune

Precision Clamping

Dial in the exact 0-10mm travel needed to clamp delicate workpieces without over-traveling or damaging the part.

settings_input_component

Machine Setup

Fine-tune the end-stop position during initial machine commissioning, avoiding the need to physically swap cylinders.

precision_manufacturing

Product Changeover

Quickly adjust the retract end-position on a production line when switching between product sizes or varying material thicknesses.

Is the Airtac SAIJ40 Adjustable Cylinder SAIJ40X10-10 the Right Cylinder?

Choose this adjustable-stroke model when you need precise end-position tuning at commissioning or during product changeover without swapping the cylinder or adding external stops. If your application requires less force, stepping down to a bore 32 SAIJ yields 563N at 0.7MPa; if you need more clamping power, a bore 50 provides 1374N.

When matching ISO 15552 replacements, verify the 10mm stroke, 10mm adjustment range, PT port, and the reduced SAIJ mounting set (Basic, FA, LB, TC, FTC, TCM1, TCM2). Because the nominal stroke is only 10mm, side-load risks are minimal, but an external guide is still recommended for heavy loads.

AirtacDistr lists every SAIJ40 order code with its price on one page at https://airtacdistr.com/products/airtac-saij40-adjustable-cylinder

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/NPT/G)
  • ✓ Magnet (-S) for sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SAIJ40 Adjustable Cylinder SAIJ40X10-10 FAQ

The rear adjuster acts as a mechanical stop that lets you trim the effective travel back by up to 10mm. This creates a 0-10mm usable window, allowing precise end-position tuning without replacing the cylinder.
