Airtac SC100 Standard Cylinder SC100X1000SCB
The AirTAC Airtac SC100 Standard Cylinder SC100X1000SCB is a genuine double-acting standard air cylinder with a Ø100mm bore and 1000mm stroke, PT1/2 air ports and adjustable end cushioning. It is used for push, pull, lift and clamp motion in industrial automation.
- BoreØ100 mm
- Stroke1000 mm
- Port sizePT1/2
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 29 mm
About the Airtac SC100 Standard Cylinder SC100X1000SCB
The SC100X1000SCB is a double-acting pneumatic cylinder delivering 3927 N of push force at 0.5 MPa, scaling up to 7068 N at 0.9 MPa. With a 100 mm bore and a 1000 mm stroke, this model is built for long linear movements in heavy automation machinery. The 25 mm diameter piston rod and PT1/2 ports provide robust, high-flow actuation.
This configuration includes a built-in magnet (-S) for direct mounting of CMSG/DMSG/EMSG sensors, enabling precise end-of-stroke detection. The rear double clevis mount (CB) with accessory F-SC100CB allows the cylinder to pivot during operation, accommodating angular motion on heavy guided structures. The adjustable air cushion decelerates the piston smoothly, protecting end caps from impact at high speeds.
Airtac SC100 Standard Cylinder SC100X1000SCB Technical Specifications
| Model | Airtac SC100 Standard Cylinder SC100X1000SCB |
|---|---|
| Series | SC standard tie-rod cylinder |
| Bore size | Ø100 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | PT1/2 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 29 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SC series datasheet. Operating pressure 0.15–1.0 MPa, proof pressure 1.5 MPa, temperature −20 to +70 °C. Confirm against the product label before installation. Thread options: PT (standard) / G.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa | 5498 N | — |
| Max (approx.) | 801 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SC100 Standard Cylinder SC100X1000SCB
| SC | Standard tie-rod cylinder series. |
|---|---|
| 100 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related variants: SCD (double rod), SCJ (adjustable stroke), SCT (multi-position). Seals: TPU standard / H = Viton / N = NBR. Thread: blank = PT, G = G thread.
Where the Airtac SC100 Standard Cylinder SC100X1000SCB Is Used
Pallet Transfer Systems
The 1000 mm stroke pushes heavy pallets across roller conveyors. The rear clevis mount allows the cylinder body to pivot, preventing rod binding on long transfer carriages.
Heavy-Duty Clamping Fixtures
Generates up to 7068 N of clamping force for welding jigs. The magnetic piston enables sensor feedback to confirm the clamp is fully engaged before the cycle starts.
Material Lift Assist
Provides 3681 N of pulling force to counterbalance heavy tooling on vertical axes. The adjustable cushioning ensures a soft stop even under high inertial loads.
Is the Airtac SC100 Standard Cylinder SC100X1000SCB the Right Cylinder?
Select the SC100 when your application requires a force class around 3927 N at standard plant pressure. If you need a more compact solution with lower force, the SC80 bore provides 2513 N of push force at 0.5 MPa. For strokes of 1000 mm, always evaluate side-load conditions; an unsupported 25 mm rod at full extension is vulnerable to bending under radial loads. Use external linear guides or a guided cylinder variant to ensure rod bearing longevity.
For a direct replacement, match five critical points: 100 mm bore, 1000 mm stroke, PT1/2 port thread, the rear double clevis mount (CB), and the built-in magnet (-S). This ensures the sensor brackets and pivot pin align perfectly with your existing machine setup.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SC100 Standard Cylinder SC100X1000SCB FAQ
At 0.5 MPa operating pressure, the push force is 3927 N and the pull force is 3681 N. At the maximum operating pressure of 0.9 MPa, the push force increases to 7068 N. The theoretical maximum force at 1.0 MPa is 801 kgf.
No. The AirTAC SC series is a tie-rod cylinder that is physically shorter than an ISO 15552 profile cylinder. It is not dimensionally interchangeable with ISO 15552 standards. For a correct replacement, you must match another AirTAC SC tie-rod cylinder with the same 100 mm bore, 1000 mm stroke, PT ports, CB clevis mount, and built-in magnet.
