Airtac SC100 Standard Cylinder SC100X1000SH
The AirTAC Airtac SC100 Standard Cylinder SC100X1000SH is a genuine double-acting standard air cylinder with a Ø100mm bore and 1000mm stroke, PT1/2 air ports and adjustable end cushioning. It is used for push, pull, lift and clamp motion in industrial automation.
- BoreØ100 mm
- Stroke1000 mm
- Port sizePT1/2
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 29 mm
About the Airtac SC100 Standard Cylinder SC100X1000SH
The SC100X1000SH is a double-acting pneumatic cylinder delivering 3927 N push force at 0.5 MPa, scaling to 7068 N at 0.9 MPa. Its 100 mm bore and 1000 mm stroke suit long-travel linear actuation, while the built-in magnet enables direct mounting of CMSG/DMSG/EMSG sensors for reliable end-of-stroke detection.
This model is equipped with Viton (FKM) seals, extending the operating temperature range to 0–150 °C for hot or aggressive environments. The 25 mm diameter piston rod, PT1/2 ports, and 29 mm adjustable air cushion provide smooth deceleration, with a body length A of 188 mm and a total extended length of approximately 1188 mm.
Airtac SC100 Standard Cylinder SC100X1000SH Technical Specifications
| Model | Airtac SC100 Standard Cylinder SC100X1000SH |
|---|---|
| Series | SC standard tie-rod cylinder |
| Bore size | Ø100 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | PT1/2 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 29 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SC series datasheet. Operating pressure 0.15–1.0 MPa, proof pressure 1.5 MPa, temperature −20 to +70 °C. Confirm against the product label before installation. Thread options: PT (standard) / G.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa | 5498 N | — |
| Max (approx.) | 801 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SC100 Standard Cylinder SC100X1000SH
| SC | Standard tie-rod cylinder series. |
|---|---|
| 100 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related variants: SCD (double rod), SCJ (adjustable stroke), SCT (multi-position). Seals: TPU standard / H = Viton / N = NBR. Thread: blank = PT, G = G thread.
Where the Airtac SC100 Standard Cylinder SC100X1000SH Is Used
Long-Stroke Material Transfer
Pushes or pulls heavy pallets and components across 1-meter spans on roller conveyors, with sensor feedback confirming full extension and retraction.
Hot Press & Mould Clamping
Applies 7 kN clamping force in heated forming or laminating presses, where Viton seals maintain integrity at sustained elevated temperatures.
High-Temperature Damper Actuation
Operates exhaust dampers or furnace doors in foundries and heat-treat lines, using the -S magnet for position confirmation in low-visibility hot zones.
Is the Airtac SC100 Standard Cylinder SC100X1000SH the Right Cylinder?
For higher force, step up to the SC125 bore (6136 N at 0.5 MPa); for a more compact footprint, the SC80 bore offers 2513 N. At 1000 mm stroke, side-load management is critical—always support the rod externally or use a guided cylinder to prevent bending and premature bearing wear. This cylinder is a direct replacement for another AirTAC SC100X1000SH with PT ports, built-in magnet, and Viton seals; verify bore, stroke, port thread, sensor compatibility, and mounting accessory match exactly.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SC100 Standard Cylinder SC100X1000SH FAQ
At 0.5 MPa, it delivers 3927 N pushing and 3681 N pulling. At the maximum operating pressure of 0.9 MPa, push force reaches 7068 N. The theoretical maximum at 1.0 MPa is 801 kgf.
Match five points: 100 mm bore, 1000 mm stroke, PT1/2 port thread, built-in magnet (-S) for sensors, and Viton (FKM) seals for high-temperature compatibility. The SC is a tie-rod cylinder, not an ISO 15552 profile, so dimensional interchangeability is limited to another AirTAC SC100 of the same configuration.
