Airtac SC100 Standard Cylinder SC100X1000SLB
$274.27
Regular price
$281.77
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SC100X1000SLB
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Enterprise-standard cylinder design optimized for industrial applications;
2. Features proprietary asymmetric bidirectional piston sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Tie-rod construction with pillar-connected end covers and aluminum tube barrel ensuring enhanced structural reliability;
4. SC Series cylinders feature more compact length versus ISO15552 standard cylinders at equivalent bore sizes;
5. Precision-engineered adjustable cushioning system for smooth stroke termination;
6. Comprehensive range of bore sizes and modular mounting accessories available for flexible configuration;
7. High-temperature resistant sealing materials enable operational range of 0~150°C.
Category: Piston Cylinders | Brand: AirTAC | Series: SC100
Installation note:
Requires rigid mounting surface (flatness ≤0.1mm/m) for 1000mm stroke applications.
Use rod support guides when stroke length exceeds 800mm. Lubricate with ISO VG32
hydraulic oil through air line lubricator (oil mist type).
Critical parameters:
Maximum piston speed 500 mm/s. Do NOT use in free air temperature exceeding 80℃
without heat shields. Requires 40μm filtered air with dew point -20℃ below ambient.
2. Features proprietary asymmetric bidirectional piston sealing structure with compact dimensions and integrated oil reservoir functionality;
3. Tie-rod construction with pillar-connected end covers and aluminum tube barrel ensuring enhanced structural reliability;
4. SC Series cylinders feature more compact length versus ISO15552 standard cylinders at equivalent bore sizes;
5. Precision-engineered adjustable cushioning system for smooth stroke termination;
6. Comprehensive range of bore sizes and modular mounting accessories available for flexible configuration;
7. High-temperature resistant sealing materials enable operational range of 0~150°C.
Category: Piston Cylinders | Brand: AirTAC | Series: SC100
AirTAC SC100X1000SLB Standard Cylinder Technical Details
- Model: SC100X1000SLB
- Bore size: Ø100 mm
- Stroke: 1000 mm
- Operation: Double-acting
- Working pressure: 0.15–0.8 MPa (21.7–116 psi)
- Cushioning: Adjustable air cushion (both ends)
- Material:
- Cylinder tube: Hard anodized aluminum alloy
- Piston rod: Chrome-plated steel (Ø25mm rod diameter)
- End caps: Extruded aluminum
- Seal type: NBR (Nitrile) seals standard, optional FKM/Viton
- Temperature range: -20℃ to +80℃ (-4°F to +176°F)
- Port size: G3/8 (ISO 228 standard)
- Mounting types: Front flange (ISO 15552 MF1), rear foot (ISO 15552 MB1), or optional side mounts
- Weight: Approximately 15.8 kg (34.8 lbs)
- Dimensions:
- Total length: 1200 mm (stroke + 200mm end structure)
- External diameter: 110 mm
- Mounting center spacing: 160 mm (front flange pattern)
- Rod thread: M16x1.5 male
- Position detection: Built-in magnet (SLB series feature) for proximity sensor mounting
High-thrust industrial cylinder designed for heavy-duty linear motion applications requiring extended stroke precision. Features corrosion-resistant construction with hard-coated inner tube surface (Ra≤0.2μm) for smooth operation. Integrated cushioning adjustment screws allow precise deceleration control at stroke ends. Compatible with ISO 15552 mounting accessories.
Typical Applications:
- Automotive production line clamping/positioning
- Plastic injection molding machine ejectors
- Steel coil handling systems
- Paper mill roller positioning
- Large-scale automated gate controls
Installation note:
Requires rigid mounting surface (flatness ≤0.1mm/m) for 1000mm stroke applications.
Use rod support guides when stroke length exceeds 800mm. Lubricate with ISO VG32
hydraulic oil through air line lubricator (oil mist type).
Critical parameters:
Maximum piston speed 500 mm/s. Do NOT use in free air temperature exceeding 80℃
without heat shields. Requires 40μm filtered air with dew point -20℃ below ambient.
| Property | Property Value |
|---|---|
| sku | SC100X1000SLB |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <1000mm> |
