Airtac SC100 Standard Cylinder SC100X1000TC
The AirTAC Airtac SC100 Standard Cylinder SC100X1000TC is a genuine double-acting standard air cylinder with a Ø100mm bore and 1000mm stroke, PT1/2 air ports and adjustable end cushioning. It is used for push, pull, lift and clamp motion in industrial automation.
- BoreØ100 mm
- Stroke1000 mm
- Port sizePT1/2
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 29 mm
About the Airtac SC100 Standard Cylinder SC100X1000TC
The AirTAC SC100X1000TC is a double-acting pneumatic cylinder engineered for long linear strokes in pivoting applications. With a 100 mm bore and 1000 mm stroke, it generates 3927 N of push force at 0.5 MPa and up to 7068 N at 0.9 MPa, driven by a 25 mm diameter piston rod.
This model features a centre trunnion (TC) mount, supplied with the TCM1 bracket (part code F-SC100TC), allowing the cylinder to pivot as it actuates. The tie-rod construction keeps the overall body length to 188 mm plus stroke, making it shorter than a comparable ISO 15552 profile cylinder. It includes an adjustable air cushion (29 mm length) to decelerate the piston smoothly at end-of-stroke.
Airtac SC100 Standard Cylinder SC100X1000TC Technical Specifications
| Model | Airtac SC100 Standard Cylinder SC100X1000TC |
|---|---|
| Series | SC standard tie-rod cylinder |
| Bore size | Ø100 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | PT1/2 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 29 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SC series datasheet. Operating pressure 0.15–1.0 MPa, proof pressure 1.5 MPa, temperature −20 to +70 °C. Confirm against the product label before installation. Thread options: PT (standard) / G.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa | 5498 N | — |
| Max (approx.) | 801 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SC100 Standard Cylinder SC100X1000TC
| SC | Standard tie-rod cylinder series. |
|---|---|
| 100 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related variants: SCD (double rod), SCJ (adjustable stroke), SCT (multi-position). Seals: TPU standard / H = Viton / N = NBR. Thread: blank = PT, G = G thread.
Where the Airtac SC100 Standard Cylinder SC100X1000TC Is Used
Long-Stroke Material Transfer
Provides a 1000 mm linear throw for pushing or pulling heavy bins and pallets across roller conveyors, with the trunnion mount absorbing alignment shifts.
Pivoting Clamp Fixtures
The TC centre trunnion allows the cylinder body to swing, making it ideal for welding jigs and assembly fixtures where the tooling must retract completely.
Farm Implement Actuation
Delivers high force for long-travel movements on agricultural equipment like chute diverters or gate openers, operating reliably on filtered compressed air.
Is the Airtac SC100 Standard Cylinder SC100X1000TC the Right Cylinder?
Choose the SC100 for applications needing around 3927 N of force at standard plant pressure; stepping down to an 80 mm bore reduces force to 2513 N, while moving up to a 125 mm bore provides 6136 N. The 1000 mm stroke is within the standard maximum of 1500 mm for this bore.
For strokes of this length, never subject the rod to side loads without an external guide. The unsupported 25 mm rod can bend under lateral force, leading to bearing wear and seal failure. To replace an existing cylinder, match bore, stroke, PT port thread, the TC centre trunnion mount, and the absence of a magnet option exactly.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SC100 Standard Cylinder SC100X1000TC FAQ
At 0.7 MPa (7 bar) supply pressure, the SC100 bore generates a theoretical push force of 5497 N. The pull force on the return stroke is 3681 N due to the 25 mm rod reducing the effective piston area.
No. The SC100 is a double-acting cylinder and will drift or drop if air pressure is lost or the directional valve is centred. To hold a load or position without live pressure, you must add an external rod lock, a mechanical brake, or a pilot-operated check valve.
