AirTAC SEJ Series · ISO 15552 Adjustable-Stroke Cylinder

Airtac SEJ Adjustable Cylinder SEJ32X120-10S

The AirTAC SEJ Adjustable Cylinder SEJ32X120-10S is a genuine double-acting ISO 15552 double-rod cylinder with a mechanically ADJUSTABLE stroke: a back-rod stop screw lets you fine-tune the retract end over a 10mm window, so this Ø32mm unit covers an effective stroke of 110–120mm without changing cylinders. Force is equal in both directions.

  • BoreØ32 mm
  • Nominal stroke120 mm
  • Adjust window10 mm
  • Effective stroke110–120 mm
  • Port sizePT1/8
  • CushionAdjustable, 27 mm
$73.01 $80.51Save 9% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SEJ32 stroke, mounting and version on one page All SEJ32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SEJ Adjustable Cylinder SEJ32X120-10S

The AirTAC SEJ32X120-10S is a double-acting, double-rod ISO 15552 profile cylinder featuring a 10mm adjustable stroke window. You can dial the retract end from 110mm to 120mm to perfectly match a machine stop.

A rear stop screw mechanically locks your fine-tuned end position. The extruded aluminum barrel has no external tie rods, and adjustable air cushions at both ends decelerate the 12mm rod near stroke extremes. Equipped with an S magnet, it supports CMSE reed and DMSE electronic sensors for position feedback.

Airtac SEJ Adjustable Cylinder SEJ32X120-10S Technical Specifications

ModelAirtac SEJ Adjustable Cylinder SEJ32X120-10S
SeriesSEJ ISO 15552 adjustable-stroke cylinder
Bore sizeØ32 mm
Nominal stroke120 mm
Adjustment window10 mm (110–120 mm)
ConfigurationDouble rod, double acting
Port sizePT1/8
Rod threadM10×1.25
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 27 mm

Specifications follow the official AirTAC SEJ datasheet and ISO 15552 / VDMA 24562 dimensions. The adjustment screw shortens the retract end only; do not exceed the 10mm window. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø32mm)

PressureForce (both directions)
0.5 MPa346 N
0.7 MPa484 N
Max (@1.0 MPa)70 kgf

A rod exits both ends, so extend and retract force are identical. Actual usable force is lower than theoretical; size with a safety margin.

Model Code: Airtac SEJ Adjustable Cylinder SEJ32X120-10S

SEJISO 15552 double-rod double-acting cylinder with adjustable stroke.
32Bore size in mm.
×120Nominal stroke length in mm.
-10Adjustment stroke window in mm (options: 10/20/30/40/50/75/100).
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting (SEJ): Basic, LB, FA, TC, FTC, TCM1, TCM2. Related: SED (double rod, fixed stroke), SE (single rod).

Where the Airtac SEJ Adjustable Cylinder SEJ32X120-10S Is Used

precision_manufacturing

Pick-and-Place Fine-Tuning

Dial the 110-120mm retract stroke to precisely match a pick-and-place end position during machine commissioning, leveraging 345N of equal both-way force.

swap_horiz

Changeover for Part Heights

Adjust the retract stop on the fly when switching a conveyor line between different product heights, avoiding the need to swap hardware.

science

Trial Positioning Jigs

Use the 10mm window to test clamping depths on a machining jig, locking the rear stop screw exactly where the 483N at 0.7MPa force is optimized.

Is the Airtac SEJ Adjustable Cylinder SEJ32X120-10S the Right Cylinder?

Confirm this 10mm adjustment window covers your positioning range. If you need less force, the adjacent bore down is 32mm (this is the smallest size). If you require more thrust, step up to the 40mm bore, which provides 528 N both ways at 0.5 MPa. If your application never requires end-position tuning, a fixed-stroke SED cylinder is sufficient.

For a direct ISO 15552 replacement, match the 32mm bore, 120mm nominal stroke, PT1/8 port, and your mounting choice (Basic, FA, LB, TC, FTC, TCM1, or TCM2). Note that the air cushion and stop screw only set the mechanical end and decelerate motion; they do not hold position on air loss. For fail-safe holding, use an external rod lock.

AirtacDistr lists every SEJ32 order code with its price on one page at https://airtacdistr.com/products/airtac-sej32-adjustable-cylinder

Quick checklist

  • ✓ Need on-machine stroke fine-tuning?
  • ✓ Adjustment window (10mm) covers your range
  • ✓ Equal force both directions OK
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Set the stop screw within the 10mm window; lock it after adjusting.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SEJ Adjustable Cylinder SEJ32X120-10S FAQ

The 10mm window lets you mechanically dial the retract stroke from 110mm up to 120mm. You set the exact end position via a stop screw on the back rod and lock it in place.

Because the rod exits both ends, force is equal in both directions: 345 N at 0.5 MPa, 483 N at 0.7 MPa, and a maximum of 70 kgf at 1.0 MPa.
