The AirTAC SEJ Adjustable Cylinder SEJ32X120-30S is a genuine double-acting ISO 15552 double-rod cylinder with a mechanically ADJUSTABLE stroke: a back-rod stop screw lets you fine-tune the retract end over a 30mm window, so this Ø32mm unit covers an effective stroke of 90–120mm without changing cylinders. Force is equal in both directions.
The AirTAC SEJ32X120-30S is a double-acting, double-rod ISO 15552 profile cylinder featuring a 30mm adjustable stroke window, yielding an effective 90-120mm travel. A rod exits both ends, ensuring identical annulus areas for equal force and speed in both directions at 345N (0.5MPa). The rear back-rod stop screw lets you dial in the retract end-position precisely on the machine before locking it down.
This 32mm bore unit includes a -S magnet for CMSE (reed) or DMSE (electronic) sensors and provides field-adjustable air cushions at both ends. It runs at 30-800mm/s with a PT1/8 port and M10x1.25 rod thread.
| Model | Airtac SEJ Adjustable Cylinder SEJ32X120-30S |
|---|---|
| Series | SEJ ISO 15552 adjustable-stroke cylinder |
| Bore size | Ø32 mm |
| Nominal stroke | 120 mm |
| Adjustment window | 30 mm (90–120 mm) |
| Configuration | Double rod, double acting |
| Port size | PT1/8 |
| Rod thread | M10×1.25 |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
Specifications follow the official AirTAC SEJ datasheet and ISO 15552 / VDMA 24562 dimensions. The adjustment screw shortens the retract end only; do not exceed the 30mm window. Port options: PT (standard) / G (BSPP).
| Pressure | Force (both directions) |
|---|---|
| 0.5 MPa | 346 N |
| 0.7 MPa | 484 N |
| Max (@1.0 MPa) | 70 kgf |
A rod exits both ends, so extend and retract force are identical. Actual usable force is lower than theoretical; size with a safety margin.
| SEJ | ISO 15552 double-rod double-acting cylinder with adjustable stroke. |
|---|---|
| 32 | Bore size in mm. |
| ×120 | Nominal stroke length in mm. |
| -30 | Adjustment stroke window in mm (options: 10/20/30/40/50/75/100). |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting (SEJ): Basic, LB, FA, TC, FTC, TCM1, TCM2. Related: SED (double rod, fixed stroke), SE (single rod).
Dial in the exact 90-120mm retract stop when calibrating a small pneumatic press, utilizing the 345N both-way force to test ejection springs without changing cylinder hardware.
Adjust the mechanical end position on the fly when switching carton sizes, using the 30mm window to match new flap heights while maintaining equal push and pull forces.
Fine-tune the lower gripper jaw position during machine commissioning, locking the back-rod stop screw once the 483N (0.7MPa) transfer alignment is perfect.
Confirm this 30mm adjustment window covers your required end-position variance. If you need less force, the neighbouring bore down is unavailable in this size range, but if you need more power, stepping up to the 40mm bore yields 528N at 0.5MPa. If your application never requires stroke changes, a fixed-stroke SED cylinder is sufficient. For ISO 15552 replacements, match the 32mm bore, 120mm nominal stroke, PT1/8 port, and your mounting choice (Basic, FA, LB, TC, FTC, TCM1, or TCM2). Note that the adjustable cushion decelerates the load near stroke end but does not hold position on air loss; for fail-safe holding, use an external rod lock.
AirtacDistr lists every SEJ32 order code with its price on one page at https://airtacdistr.com/products/airtac-sej32-adjustable-cylinder
Quick checklist
The 30mm adjustment window allows you to mechanically dial in the retract stroke from 90mm up to 120mm. You set the exact end-position via the back-rod stop screw and lock it in place, meaning one cylinder covers a range of travel without hardware swaps.
Because a rod exits both ends, force is identical in both directions: 345N at 0.5MPa, 483N at 0.7MPa, and a maximum of 70kgf at 1.0MPa.
