AirTAC SGC Series · Large-Bore ISO 15552 Cylinder

Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-100

The AirTAC SGCJ125~160 Adjustable Cylinder SGCJ125X100-100 is a genuine double acting, double rod, adjustable stroke ISO 15552 (orig. ISO 6431) tie-rod air cylinder with a Ø125mm bore and 100mm stroke, G1/2 air ports and adjustable end cushioning. Its large-bore tie-rod build delivers high thrust and drops into standardized ISO 15552 mounting on heavy automation.

  • BoreØ125 mm
  • Stroke100 mm
  • Port sizeG1/2
  • Acting typeDouble acting, double rod, adjustable stroke
  • Rod threadM27×2.0
  • CushionAdjustable, 40 mm
$228.21 $235.71Save 3% Made to order — confirm lead time
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SGCJ125 stroke, adjustment, mounting and version on one page All SGCJ125 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-100

Four steel tie rods clamp the aluminum barrel to the covers, yielding a rigid framework that drops into existing ISO 15552 mounting-interface fixtures.

The SGCJ125X100-100 carries a 100 mm nominal stroke that can be shortened on-site by up to 100 mm via the external stop screw, while the retract end remains fixed. Air enters through a G1/2 port to drive the Ø32 mm rod, and adjustable 40 mm air cushions decelerate the piston at both ends. Note that this specific SKU lacks a magnet, so it cannot accept CMSG/DMSG/EMSG sensors; adding the -S variant enables that switch set.

Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-100 Technical Specifications

ModelAirtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-100
SeriesSGC ISO 15552 tie-rod cylinder
Bore sizeØ125 mm
Stroke100 mm
Acting typeDouble acting, double rod, adjustable stroke
Port sizeG1/2
Rod threadM27×2.0
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 500 mm/s
CushionAdjustable, 40 mm
Max standard strokeUp to 1500 mm

Specifications follow the official AirTAC SGC datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Thread options: PT (blank) / G. TPU seals are not available for the Ø250 bore (NBR / Viton only).

Theoretical Output Force (Ø125mm)

PressurePush forcePull force
0.5 MPa5734 N5734 N
0.7 MPa8027 N8027 N
Max (@1.0 MPa)1169 kgf

SGCJ is double-rod: the rear rod that carries the stroke adjuster passes through the rear cover, so both piston faces lose rod area. Push is shown at the annular-area value (conservative).

Model Code: Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-100

SGCJISO 15552 tie-rod cylinder (adjustable-stroke type).
125Bore size in mm (125 / 160 / 200 / 250).
×100Stroke length in mm.
-SOptional built-in magnet for CMSG / DMSG / EMSG sensors.

SGC-family variants: SGC (double acting), SGCD (double rod), SGCJ (adjustable stroke). Mounting: LB / FA / FB / CA / CB / CR / TC / FTC / TCM1 / TCM2. Seals: TPU (blank) / Viton H / NBR N. On Ø250 the blank code is the standard NBR build (no TPU).

Where the Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-100 Is Used

precision_manufacturing

Press Fit Dialing

Fine-tune the extend stroke on-site by up to 100 mm to set precise pressing depths for bearing insertion without machining custom spacers.

conveyor_belt

Divertor Positioning

Adjust the extend stop to alter the stroke length for sorting different package sizes on a shared conveyor line using one cylinder model.

warehouse

Pallet Stop Tuning

Shorten the extend stroke on the fly to accommodate varying pallet widths at a packaging station while maintaining a fixed retract end.

Is the Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-100 the Right Cylinder?

When sizing this 125 mm bore against its neighbors, stepping down is not an option as it sits at the low edge of the SGCJ range, but stepping up to the 160 mm bore increases the 0.5 MPa push force to 10053 N. The 100 mm adjustable-stroke window is highly beneficial for sharing a single spare cylinder across multiple stroke variants or dialing in exact end positions on-site. Mounting options include FA, LB, TC, FTC, TCM1, and TCM2 brackets. Because this is a non-magnetized SKU, position sensing is impossible without upgrading to the -S version. Even at 100 mm, guide the load to prevent side-load wear.

AirtacDistr lists every SGCJ125 order code with its price on one page at https://airtacdistr.com/products/airtac-sgcj125-adjustable-double-rod-cylinder

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT / G / NPT)
  • ✓ Magnet (-S) for sensors?
  • ✓ Long-stroke side load — support the rod end
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load; support long strokes at the rod end.
  • check Set cushions to minimum, then release gradually.
  • check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SGCJ125~160 Adjustable Cylinder SGCJ125X100-100 FAQ

The theoretical max force is 1251 kgf at 1.0 MPa. The air port size is G1/2.

The 100 mm nominal stroke is the maximum extend length. The external adjuster allows you to shorten the usable extend stroke on-site by up to 100 mm, down to zero. The retract end is fixed, and this stop mechanism is for positioning only, not for holding a load.
