Airtac SULB Lock Cylinder SULB100X200
2. Release mechanisms: Automatic and Manual.
Category: Locking Cylinders , Brand: AirTAC , Series: SULB
AirTAC SULB100X200 Locking Cylinder Technical Details
- Model: SULB100X200
- Type: Double-acting cylinder with mechanical locking
- Bore size: Ø100mm
- Stroke: 200mm
- Operating pressure: 0.1–0.8 MPa
- Locking mechanism: Spring-activated mechanical brake
- Port size: 1/2" NPT (G1/2 optional)
- Cushioning: Adjustable pneumatic cushion
- Temperature range: -10℃ to 80℃
- Body material: Aluminum alloy (piston rod: chrome-plated steel)
- Seal material: NBR + Polyurethane hybrid
- Protection rating: IP67 (dust/water resistant)
- Weight: 5.8kg (excluding accessories)
- Dimensions: 380mm(L) × 128mm(W) × 128mm(H)
Industrial-grade locking cylinder featuring fail-safe position retention through integrated mechanical braking. The dual-lip seal design ensures zero drift under 0.3MPa holding force, with corrosion-resistant construction for harsh environments. Requires 5μm filtered air and ISO VG32 hydraulic oil lubrication.
- Vertical load holding in automated assembly lines
- Emergency stop positioning in material handling systems
- Press machine intermediate position locking
- Theatrical equipment safety brakes
- Wind turbine blade adjustment mechanisms
Installation guidelines:
Maintain ≤0.5mm/m alignment tolerance during mounting. Engage locking mechanism only when piston speed drops below 50mm/s.
Requires weekly lubrication through air line lubricator (oil mist ratio 1:1500).
| Property | Property Value |
|---|---|
| sku | SULB100X200 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | <200mm> |
| Lock Position | Rear Cover with Lock Type |
