Airtac SULB Lock Cylinder SULB100X25-S
$182.71
Regular price
$190.21
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SULB100X25-S
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Locking cylinder configurations include: Front Cover Locking Type and Rear Cover Locking Type;
2. Release mechanisms: Automatic and Manual.
Category: Locking Cylinders , Brand: AirTAC , Series: SULB
Installation note:
Lock engagement requires 80% of rated pressure. Always disengage lock before manual override.
Lubricate lock mechanism with ISO VG32 hydraulic oil monthly. Maintain 0.3mm minimum clearance
between lock unit and mounting surface.
Critical parameters:
2. Release mechanisms: Automatic and Manual.
Category: Locking Cylinders , Brand: AirTAC , Series: SULB
AirTAC SULB100X25-S Locking Cylinder Specifications
- Model: SULB100X25-S
- Type: Double-acting cylinder with mechanical lock
- Bore size: Ø100 mm
- Stroke: 25 mm (customizable up to 500 mm)
- Operating pressure: 0.1–0.8 MPa
- Locking force: 785 N @ 0.8 MPa
- Mounting style: Standard MF1 (front flange)
- Cushioning: Adjustable rubber buffer
- Seal material: NBR + PU combination
- Temperature range: -20℃ to 80℃
- Protection rating: IP65 (standard rod wiper)
- Weight: 5.2 kg (bare cylinder), 5.8 kg (with lock unit)
- Dimensions: 200mm(L) × 100mm(W) × 100mm(H) (at mid-stroke)
- Rod thread: M20×1.5 external thread
- Lock activation: Manual release lever + auto-engage
Heavy-duty locking cylinder featuring dual safety mechanism with spring-assisted mechanical lock and pneumatic holding. The chromium-plated piston rod integrates wear-resistant coating (SUPER COAT II) for extended cycle life. Includes magnetic piston for position sensing compatibility.
Typical Applications:
- Injection molding machine clamp positioning
- Automated assembly line fixture locking
- Overhead load braking systems
- Precision welding jigs in automotive manufacturing
- Vertical elevator emergency stop mechanisms
Installation note:
Lock engagement requires 80% of rated pressure. Always disengage lock before manual override.
Lubricate lock mechanism with ISO VG32 hydraulic oil monthly. Maintain 0.3mm minimum clearance
between lock unit and mounting surface.
Critical parameters:
- Max side load: 150N (use guide rails for heavy side loads)
- Lock response time: 0.5s @ 0.5MPa
- Repeat positioning accuracy: ±0.2mm
| Property | Property Value |
|---|---|
| sku | SULB100X25-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | <25 mm> |
| Lock Position | Rear Cover with Lock Type |
