Airtac SULB Lock Cylinder SULB100X75-S
2. Release mechanisms: Automatic and Manual.
Category: Locking Cylinders , Brand: AirTAC , Series: SULB
AirTAC SULB100X75-S Locking-Type Cylinder Specifications
- Model: SULB100X75-S
- Type: Double-acting cylinder with mechanical lock
- Bore size: Ø100 mm
- Stroke: 75 mm
- Operating pressure: 0.05–1.0 MPa
- Locking force: 4,500 N (max at 0.5 MPa)
- Lock activation: Pneumatic release (0.15–1.0 MPa)
- Cushioning: Adjustable elastic cushion (both ends)
- Mounting type: Basic (standard foot mounting)
- Port size: G3/8 (NPT1/2 optional)
- Operating temperature: -10℃ to 80℃
- Rod material: Chrome-plated steel (S45C)
- Tube material: Anodized aluminum alloy
- Seal material: NBR + PU combination
- Weight: 5.8 kg (excluding accessories)
- Dimensions: 312mm(L) × 125mm(W) × 125mm(H)
- Protection rating: IP54 (standard wiper design)
Heavy-duty locking cylinder featuring fail-safe mechanical brake mechanism that engages automatically during power/pneumatic failure. The dual-piston lock design provides symmetrical holding force, with precision ground rod surface (Ra≤0.4μm) ensuring smooth operation. Requires 20-30μm filtered air and monthly lubrication (ISO VG32 equivalent).
- Vertical load holding in automated assembly lines
- Emergency stop positioning in material handling systems
- Precision fixturing for CNC machine tooling
- Safety brake in elevator test rigs
- Position retention in solar panel tilt mechanisms
Installation note:
Locking mechanism requires 0.3s pre-pressurization before cylinder movement.
Maintain 50mm minimum clearance around lock housing for thermal expansion.
| Property | Property Value |
|---|---|
| sku | SULB100X75-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 75mm |
| Lock Position | Rear Cover with Lock Type |
