Airtac SULB Lock Cylinder SULB40X200-S
2. Release mechanisms: Automatic and Manual.
Category: Locking Cylinders , Brand: AirTAC , Series: SULB
AirTAC SULB40X200-S Locking Cylinder Technical Specifications
- Model Code: SULB40X200-S
- Type: Double-acting cylinder with mechanical locking mechanism
- Bore size: 40mm (1-9/16")
- Stroke: 200mm (7.87")
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Locking force: 1,570N @ 0.5 MPa
- Port size: G1/8 (Rc1/8 optional)
- Cushioning: Adjustable pneumatic cushion (both ends)
- Rod material: Chrome-plated steel (Cr-Mo alloy)
- Tube material: Anodized aluminum alloy
- Seal material: NBR + Polyurethane hybrid seals
- Temperature range: -20℃ to 80℃ (-4°F to 176°F)
- Weight: 3.8kg (8.38 lbs)
- Dimensions (L×W×H):
- Retracted length: 298mm (11.73")
- Extended length: 498mm (19.61")
- Mounting base: 125×40mm (4.92"×1.57")
- Rod end thread: M16×1.5
- Protection rating: IP65 (rod extension area IP54)
- ISO standard: 15552 (previously ISO 6431)
Industrial-grade locking cylinder featuring fail-safe mechanical brake system that activates automatically during power/pressure loss. The dual-piston locking mechanism provides zero-backlash position holding, with 360° mounting flexibility. Includes wear-resistant guide bands for smooth operation under side load conditions (max 10% of thrust force).
- Vertical load stabilization in CNC tool changers
- Safety locking in injection molding clamp units
- Position retention for automated assembly robots
- Emergency stop systems for material handling elevators
- Precision fixturing in optical component manufacturing
Installation guidelines:
Lubricate with ISO VG32 hydraulic oil before initial use.
Maintain 0.3-0.5 MPa locking pressure during adjustment.
Allow 0.5mm lateral play during alignment.
Not recommended for continuous reciprocating >60 cycles/min.
| Property | Property Value |
|---|---|
| sku | SULB40X200-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Stroke | <200mm> |
| Lock Position | Rear Cover with Lock Type |
