Airtac SULB Lock Cylinder SULB40X25-S
2. Release mechanisms: Automatic and Manual.
Category: Locking Cylinders , Brand: AirTAC , Series: SULB
AirTAC SULB40X25-S Locking Cylinder Specifications
- Model: SULB40X25-S
- Type: Double-acting cylinder with mechanical lock
- Bore size: 40mm
- Stroke: 25mm
- Operating pressure: 0.1–1.0 MPa
- Locking force: ≥500N (at 0.5MPa)
- Cushioning type: Adjustable elastic cushion
- Mounting style: Basic fixed (MF1)
- Port size: M5x0.8 (G1/8 adapter optional)
- Temperature range: -10℃ to 70℃
- Rod material: Chrome-plated steel
- Tube material: Aluminum alloy (hard anodized)
- Seal type: NBR + PU combination
- Protection rating: IP54 (standard), IP67 (optional w/rod cover)
- Weight: 1.25kg ±3%
- Dimensions: 180mm(L) × 50mm(W) × 50mm(H)
Industrial-grade locking cylinder featuring fail-safe mechanical brake system with 0.1-second emergency response. The dual-piston locking mechanism maintains position during power loss, with wear-compensation design for long-term stability. Requires 5μm filtered air with ISO 8573-1:2010 Class 3 air quality.
- Vertical load holding in automated assembly lines
- Safety positioning in CNC tool changers
- Emergency stop systems for material handling
- Precision fixturing in semiconductor manufacturing
- Elevation locking in robotic palletizers
Installation notes:
Lubricate lock mechanism with ISO VG32 hydraulic oil before first use.
Maintain 0.3-0.5mm clearance between lock unit and mounting surface.
Perform monthly brake gap inspection (max tolerance: 0.2mm).
| Property | Property Value |
|---|---|
| sku | SULB40X25-S |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Stroke | <25 mm> |
| Lock Position | Rear Cover with Lock Type |
