Airtac SULB Lock Cylinder SULB40X50
2. Release mechanisms: Automatic and Manual.
Category: Locking Cylinders , Brand: AirTAC , Series: SULB
AirTAC SULB40X50 Locking Cylinder Specifications
- Model: SULB40X50
- Type: Double-acting cylinder with mechanical lock
- Bore size: 40mm
- Stroke: 50mm
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting type: Standard MF1 flange (ISO 15552 compatible)
- Locking force: 1,200N (at 0.5MPa)
- Lock release pressure: ≥0.3MPa
- Ambient temperature: -20℃ to 80℃
- Weight: 3.2kg (excluding accessories)
- Dimensions: 215mm(L) × 52mm(W) × 52mm(H)
- Rod material: Chrome-plated steel (S45C)
- Tube material: Anodized aluminum alloy
- Seal material: NBR/PU hybrid seals
- Protection rating: IP54 (standard), IP67 optional
Heavy-duty locking cylinder featuring dual-position mechanical brake mechanism for mid-stroke position holding. The integrated wedge-lock system engages automatically during pressure loss, with manual override capability. Optimized for vertical installations requiring fail-safe load holding.
- Automated welding fixture position retention
- Vertical press machine emergency stop systems
- Overhead material handling equipment
- Injection molding machine core pull mechanisms
- Elevator safety brake actuators
Installation note:
Requires minimum 0.25MPa locking pressure before load application.
Lubricate guide shafts monthly with ISO VG32 hydraulic oil.
Avoid side-load forces exceeding 50N during operation.
| Property | Property Value |
|---|---|
| sku | SULB40X50 |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | <50mm> |
| Lock Position | Rear Cover with Lock Type |
