Airtac 2V Fluid Control Valve 2V02506B
1. Direct-acting normally closed 2-port 2-position solenoid valve with rapid and responsive switching characteristics;
2. Lightweight and compact structural design;
3. Features brass valve body construction, Class B thermal-rated electromagnetic coil, and fluorinated rubber (VITON) seals compatible with multiple media types;
2V130/250 Series
1. Diaphragm pilot-operated 2-port 2-position solenoid valve offering low power consumption and high flow capacity;
2. Low cracking pressure requirement with minimum operating pressure differential of 0.05MPa;
3. Constructed with brass valve body, Class B thermal-rated electromagnetic coil, and Nitrile Butadiene Rubber (NBR) sealing components;
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2V
AirTAC 2V02506B Fluid Control Valve Specifications
- Model: 2V02506B
- Type: 2-position, 5-port direct-acting solenoid valve
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.1–1.0 MPa
- Voltage options: DC12V, DC24V, AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 320g ±5%
- Dimensions: 62mm(L) × 48mm(W) × 84mm(H)
- Seal material: FKM (Viton) fluorocarbon rubber
- Temperature range: -10℃ to 80℃ (non-freezing)
- Flow capacity: 850 l/min (ANR)
- Power consumption: 2.5W (DC), 3.2VA (AC)
- Response time: ≤15ms (exhaust to actuation)
- Protection rating: IP67 (dust/water resistant)
- Port thread depth: 12mm (minimum engagement)
High-flow pneumatic valve with dual-pressure capability, featuring brass body construction with chrome-plated spool for reduced friction. Designed for aggressive duty cycles (≥10 million operations) with manual override option. Requires 5μm filtered air with ISO 8573-1:2010 Class 3.4 air quality.
- Industrial automation: CNC tool changers & clamp systems
- Food processing machinery: Pneumatic actuator control
- Medical gas systems: Oxygen line switching mechanisms
- Water treatment plants: Backwash valve sequencing
- Automotive testing rigs: Air cylinder synchronization
Installation protocol:
Mount horizontally with arrow aligned to flow direction.
Use anti-vibration washers in high-shock environments.
Lubricate seals with ISO VG32 pneumatic oil during maintenance.
Critical note:
Do NOT use with ethylene glycol-based fluids.
Minimum 80% duty cycle required for continuous operation.
Allow 15-minute cooldown after 2hrs of 100% load.
| Property | Property Value |
|---|---|
| sku | 2V02506B |
| Port Size | PT1/8 |
| Flow Aperture | <2.5 mm> |
| Coil Voltage | DC24V |
