Airtac 2V Fluid Control Valve 2V02506CI
1. Direct-acting normally closed 2-port 2-position solenoid valve with rapid and responsive switching characteristics;
2. Lightweight and compact structural design;
3. Features brass valve body construction, Class B thermal-rated electromagnetic coil, and fluorinated rubber (VITON) seals compatible with multiple media types;
2V130/250 Series
1. Diaphragm pilot-operated 2-port 2-position solenoid valve offering low power consumption and high flow capacity;
2. Low cracking pressure requirement with minimum operating pressure differential of 0.05MPa;
3. Constructed with brass valve body, Class B thermal-rated electromagnetic coil, and Nitrile Butadiene Rubber (NBR) sealing components;
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2V
AirTAC 2V02506CI Fluid Control Valve Specifications
- Model: 2V02506CI
- Type: 2-position, 5-way pilot-operated (double solenoid)
- Port size: PT1/4 (G1/4 equivalent)
- Thread standard: ISO standard tapered pipe thread (Rc)
- Operating pressure: 0.05–1.0 MPa
- Max flow rate: 750 L/min (ANR)
- Voltage options: DC12V (±10%), DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 0.68 kg ±5%
- Dimensions: 59mm(L) × 45mm(W) × 90mm(H) (excluding connectors)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -5℃ to 80℃ (no freezing)
- Power consumption: 2.2W (DC), 3.5VA (AC)
- Response time: ≤30ms (exhaust to atmosphere)
- Protection rating: IP67 (coil assembly)
- Port alignment: ISO 5599-1 standard (interchangeable with competitor models)
High-flow 5/2-way valve with dual manual override and LED status indicator. Features brass main body with hard anodized aluminum solenoid housing for EMI protection. Designed for applications requiring rapid cycling (up to 5Hz) and medium-pressure pneumatic systems. Requires 5μm filtered lubricated air (ISO 8573-1:2010 Class 4-4-3).
- Automated assembly line clamping mechanisms
- Plastic injection molding machine ejectors
- CNC machine tool chuck control systems
- Automotive tire inflation stations
- Food packaging equipment with vertical form-fill-seal (VFFS) machines
Installation note:
Mount using M5 mounting screws with vibration-proof washers. Maintain minimum 20mm
clearance below valve for exhaust port airflow. For dual solenoid models, install
surge suppressors within 0.5m of coil connections. Lubricate seals with ISO VG32
turbine oil if operating below -5℃.
| Property | Property Value |
|---|---|
| sku | 2V02506CI |
| Port Size | PT1/8 |
| Flow Aperture | <2.5 mm> |
| Coil Voltage | AC 110V |
