Airtac 2V Fluid Control Valve 2V13010AI
1. Direct-acting normally closed 2-port 2-position solenoid valve with rapid and responsive switching characteristics;
2. Lightweight and compact structural design;
3. Features brass valve body construction, Class B thermal-rated electromagnetic coil, and fluorinated rubber (VITON) seals compatible with multiple media types;
2V130/250 Series
1. Diaphragm pilot-operated 2-port 2-position solenoid valve offering low power consumption and high flow capacity;
2. Low cracking pressure requirement with minimum operating pressure differential of 0.05MPa;
3. Constructed with brass valve body, Class B thermal-rated electromagnetic coil, and Nitrile Butadiene Rubber (NBR) sealing components;
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2V
AirTAC 2V13010AI Fluid Control Valve Specifications
- Model: 2V13010AI
- Type: 5-port 2-position solenoid valve (Double solenoid)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Voltage options: DC24V (±10%), AC110V (50/60Hz), AC220V (50/60Hz)
- Weight: 310g ±5% (with connectors)
- Dimensions: 58mm(L) × 42mm(W) × 78mm(H)
- Seal material: Heat-resistant NBR (Nitrile Butadiene Rubber)
- Temperature range: -20℃ to 80℃ (with intermittent operation up to 100℃)
- Power consumption: ≤2.2W (DC) / ≤3.5VA (AC)
- Flow coefficient (Cv): 1.8
- Response time: ≤15ms (excitation), ≤20ms (de-excitation)
- Protection rating: IP67 (Dust-tight and protected against immersion)
- Port thread depth: 12mm (minimum engagement length)
High-flow directional control valve with dual solenoid operation, featuring optimized spool geometry for reduced pressure drop. The hardened stainless steel shaft and reinforced polymer sleeve ensure 5-million-cycle durability. Includes manual override and surge suppression circuitry. Compatible with ISO 15407-1 standards.
- Automated assembly line actuators
- Plastic injection molding machine clamp control
- CNC tool changers and pallet systems
- Industrial robotic gripper sequencing
- Packaging machine cylinder synchronization
Installation note:
For optimal performance, maintain 0.5-1.0mm clearance between valve base and manifold surface.
Use PTFE tape on port threads with 1.5-2 full wraps. Lubricate seals with silicone grease (JIS K2220)
during maintenance. Avoid mounting near high-frequency vibration sources (>200Hz).
| Property | Property Value |
|---|---|
| sku | 2V13010AI |
| Port Size | PT3/8 |
| Flow Aperture | 13mm |
| Coil Voltage | AC220V |
