Airtac 2V Fluid Control Valve 2V13010BI
1. Direct-acting normally closed 2-port 2-position solenoid valve with rapid and responsive switching characteristics;
2. Lightweight and compact structural design;
3. Features brass valve body construction, Class B thermal-rated electromagnetic coil, and fluorinated rubber (VITON) seals compatible with multiple media types;
2V130/250 Series
1. Diaphragm pilot-operated 2-port 2-position solenoid valve offering low power consumption and high flow capacity;
2. Low cracking pressure requirement with minimum operating pressure differential of 0.05MPa;
3. Constructed with brass valve body, Class B thermal-rated electromagnetic coil, and Nitrile Butadiene Rubber (NBR) sealing components;
Category: Fluid Solenoid Valves | Brand: AirTAC | Series: 2V
AirTAC 2V13010BI Fluid Control Valve Technical Details
- Model: 2V13010BI
- Type: 5/2-way monostable solenoid valve (direct-acting)
- Port size: PT1/4 (G1/4 optional)
- Operating pressure: 0.2–1.0 MPa (29–145 PSI)
- Voltage variants: DC12V/24V, AC110V/220V (±10% tolerance)
- Flow rate: 850 L/min (Cv=1.2 at 0.5 MPa)
- Response time: ≤15ms (energize), ≤20ms (de-energize)
- Weight: 320g ±5% (excluding connectors)
- Dimensions: 56mm(L) × 40mm(W) × 78mm(H)
- Seal material: Heat-resistant FKM fluorocarbon rubber
- Temperature range: -10℃ to 120℃ (with dry air)
- Power consumption: 2.8W (AC), 3.5W (DC)
- Port thread depth: 12mm (minimum engagement)
- Protection class: IP67 (dust/immersion resistant)
- Cycle life: ≥10 million operations
High-flow 5/2-way valve engineered for demanding pneumatic circuits requiring rapid cycling. Features zero-pressure start capability and a copper-free aluminum alloy body for corrosion resistance in humid environments. The dual-coil design allows manual override via built-in pushbutton. Compatible with ISO 15407-1 standards.
- Automated assembly line cylinder control
- Plastic injection molding machine actuators
- Textile machinery air circuit switching
- Automotive brake system testing rigs
- Food packaging vacuum/pressure systems
Installation guidelines:
Use vibration-damping mounts in high-shock environments. Lubricate seals with ISO VG32 turbine oil
during maintenance. Maintain 15mm minimum clearance from heat sources (>80℃).
Critical note:
Requires 5-10μm filtration (40μm max) with automatic drain. Avoid silicone-based lubricants
to prevent seal degradation.
| Property | Property Value |
|---|---|
| sku | 2V13010BI |
| Port Size | PT3/8 |
| Flow Aperture | 13mm |
| Coil Voltage | DC24V |
