AirTAC 4V Series · 5/2-way Solenoid Valve

Airtac 4V200 Solenoid Valve 4V220-06-A

The AirTAC 4V200 Solenoid Valve 4V220-06-A is a genuine 5/2-way double solenoid (memory) solenoid valve with PT1/8 ports and an effective area of 17.0 mm² (Cv 1.0). It is an internally piloted spool valve that directs compressed air to double-acting cylinders and actuators.

  • Valve type5/2-way
  • FunctionDouble solenoid (memory)
  • Port sizePT1/8
  • Effective area17.0 mm²
  • Flow (Cv)1.0
  • Series4V200
$40.54 $48.04Save 15% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every 4V220-06 stroke, mounting and version on one page All 4V220-06 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac 4V200 Solenoid Valve 4V220-06-A

The AirTAC 4V220-06A is a 5/2-way double-solenoid directional control valve from the popular 4V200 series, built to direct compressed air to double-acting cylinders and actuators. It operates with a memory function: a momentary pulse to one solenoid shifts the spool, and it stays locked in that last-commanded position even when power is removed—no holding current required. This AC220V version uses a 4.5 VA coil and connects through a standard terminal box.

With an effective area of 17.0 mm² and a Cv of 1.0, this 1/8-inch PT-ported valve suits pneumatic cylinders in the ~O32-50 mm range for general industrial tasks. The sliding-spool mechanism responds in 0.05 seconds or less and cycles up to 5 times per second. It shares the rugged 4V200 aluminum-alloy body rated IP65, operates on 0.15-0.8 MPa filtered air, and weighs 320 g.

Airtac 4V200 Solenoid Valve 4V220-06-A Technical Specifications

ModelAirtac 4V200 Solenoid Valve 4V220-06-A
Series4V200 solenoid valve (spool type)
Valve type5/2-way
FunctionDouble solenoid (memory)
Port sizePT1/8
Exhaust portPT1/8
Effective area (Cv)17.0 mm² (Cv 1.0)
FluidAir (filtered by 40µm element)
Pilot typeInternal / external pilot
Operating pressure0.15 – 0.8 MPa
Proof pressure1.2 MPa
Max frequency5 cycle/sec
Response time≤ 0.05 s (activating)
Temperature-20 to +70 °C
Body materialAluminum alloy
Weight320 g

Specifications follow the official AirTAC 4V series datasheet. Lubrication not required. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.

Flow & Coil Options

Effective area17.0 mm²
Flow coefficientCv 1.0
Response time≤ 0.05 s
Coil powerAC 4.5 VA · DC24V 3.0 W · DC12V 2.5 W
Protection / insulationIP65 (DIN40050), B-class
Voltage optionsDC24V, DC12V, AC110V, AC220V
Manual overrideYes (locking / non-locking)

Size the valve so effective area / Cv is not the bottleneck for your cylinder bore and speed. Undersized valves slow the actuator. Note 5/3 (center) versions have a smaller effective area than the 5/2 of the same body size.

Model Code: Airtac 4V200 Solenoid Valve 4V220-06-A

4VSolenoid valve, spool type, 4-series.
2Body size (4V200) — sets port & flow.
2Function: 1 = single 5/2, 2 = double 5/2, 3 = 5/3.
-06Port thread: M5 / 06=1/8" / 08=1/4" / 10=3/8" / 15=1/2".

Related: 4V210 (single), 4V220 (double), 4V230C/E/P (5/3 center). Add the voltage suffix when ordering.

Where the Airtac 4V200 Solenoid Valve 4V220-06-A Is Used

conveyor_belt

Pulse-Actuated Gate Control

Ideal for diverters and gates on conveyor lines where the actuator must hold its last position after a brief control pulse, eliminating the heat and energy draw of a continuously energized coil.

handyman

Clamping & Fixturing Stations

Suits assembly-jig clamps that need to stay locked during a work cycle. The memory spool keeps the clamp pressurized even if the PLC output drops, provided the circuit remains sealed.

precision_manufacturing

Packaging Machine Pushers

Drives double-acting pusher cylinders in case packers and wrappers. The 5 c/s max frequency handles rapid reciprocation, while the AC220V coil integrates easily into plant-voltage control panels.

Is the Airtac 4V200 Solenoid Valve 4V220-06-A the Right Valve?

Choose the 4V220-06A when your application needs a 5/2 valve that holds its position without a continuous electrical signal, making it ideal for energy-conscious or signal-sensitive circuits. For smaller cylinders below O32 mm, the 4V100 series (Cv 0.6) offers a more compact fit; for larger bores or faster stroke speeds above O50 mm, step up to the 4V300 series (Cv 1.65) to ensure sufficient flow.

This double-solenoid model is distinct from the spring-return 4V210: it requires only a pulse, and the spool remains in place on power loss. When replacing an existing valve, match all five points: the 4V200 body size, the 5/2 double-solenoid function, the 1/8-inch PT port, the AC220V coil voltage, and the terminal-box electrical entry. The valve can be used individually or ganged on a manifold base for multi-cylinder stations.

AirtacDistr lists every 4V220-06 order code with its price on one page at https://airtacdistr.com/products/airtac-4v220-06-solenoid-valve

Quick checklist

  • ✓ Required flow (Cv) for cylinder & speed
  • ✓ Function: single / double / 5-3 center
  • ✓ Coil voltage (DC24 / AC220 …)
  • ✓ Port thread (M5 / 1/8 / 1/4 / 3/8 / 1/2)
  • ✓ Single valve or manifold base?
Ask an Engineer

Installation & Wiring Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 0.8 MPa operating pressure.
  • check Match coil voltage to your controller output.
  • check Use the manual override to test before powering.
  • check Fit silencers or fittings to the exhaust ports.
  • check Wiring by qualified personnel per AirTAC docs.

Airtac 4V200 Solenoid Valve 4V220-06-A FAQ

It means the valve spool stays in its last pulsed position without continuous power. A momentary signal to coil A shifts the spool one way; a pulse to coil B shifts it back. The spool is held by friction and balanced pressure, not by a spring or magnet. This is useful for holding a cylinder in place during a machine stop without energizing a coil.

It can, but it is best matched to ~O32-50 mm cylinders. With a Cv of 1.0, a larger O63 mm cylinder will move noticeably slower. For a 63 mm bore or a high-speed application, the 4V300 series (Cv 1.65) is the recommended step-up to achieve faster cycle times.
