Airtac 4V200 Solenoid Valve 4V230C-06-A
The AirTAC Airtac 4V200 Solenoid Valve 4V230C-06-A is a genuine 5/3-way 5/3 double solenoid — closed center solenoid valve with A ports and an effective area of 13.6 mm² (Cv 0.8). It is an internally piloted spool valve that directs compressed air to double-acting cylinders and actuators.
- Valve type5/3-way
- Function5/3 double solenoid — Closed center
- Port sizeA
- Effective area13.6 mm²
- Flow (Cv)0.8
- Series4V200
About the Airtac 4V200 Solenoid Valve 4V230C-06-A
The AirTAC 4V230C-06A is a 5/3-way double-solenoid valve with a closed center, built on the popular 4V200 aluminum body. When both solenoids are de-energised, all ports are blocked, which locks the connected double-acting cylinder in place at its mid-stroke position—ideal for applications where the load must not drift during an emergency stop or a pause in the cycle.
This model is configured for 1/8-inch PT (Rc) tapered thread ports and operates on a 220 V AC supply, drawing 4.5 VA from the coil. With an effective area of 13.6 mm² (Cv 0.8) and a response time of 0.05 seconds or less, it provides precise, repeatable control for pneumatic actuators in the O32 to O50 mm bore range.
Airtac 4V200 Solenoid Valve 4V230C-06-A Technical Specifications
| Model | Airtac 4V200 Solenoid Valve 4V230C-06-A |
|---|---|
| Series | 4V200 solenoid valve (spool type) |
| Valve type | 5/3-way |
| Function | 5/3 double solenoid — Closed center |
| Port size | A |
| Exhaust port | A |
| Effective area (Cv) | 13.6 mm² (Cv 0.8) |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Pilot type | Internal / external pilot |
| Operating pressure | 0.15 – 0.8 MPa |
| Proof pressure | 1.2 MPa |
| Max frequency | 3 cycle/sec |
| Response time | ≤ 0.05 s (activating) |
| Temperature | -20 to +70 °C |
| Body material | Aluminum alloy |
| Weight | 360 g |
Specifications follow the official AirTAC 4V series datasheet. Lubrication not required. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.
Flow & Coil Options
| Effective area | 13.6 mm² |
|---|---|
| Flow coefficient | Cv 0.8 |
| Response time | ≤ 0.05 s |
| Coil power | AC 4.5 VA · DC24V 3.0 W · DC12V 2.5 W |
| Protection / insulation | IP65 (DIN40050), B-class |
| Voltage options | DC24V, DC12V, AC110V, AC220V |
| Manual override | Yes (locking / non-locking) |
Size the valve so effective area / Cv is not the bottleneck for your cylinder bore and speed. Undersized valves slow the actuator. Note 5/3 (center) versions have a smaller effective area than the 5/2 of the same body size.
Model Code: Airtac 4V200 Solenoid Valve 4V230C-06-A
| 4V | Solenoid valve, spool type, 4-series. |
|---|---|
| 2 | Body size (4V200) — sets port & flow. |
| 3 | Function: 1 = single 5/2, 2 = double 5/2, 3 = 5/3. |
| -A | Port thread: M5 / 06=1/8" / 08=1/4" / 10=3/8" / 15=1/2". |
Related: 4V210 (single), 4V220 (double), 4V230C/E/P (5/3 center). Add the voltage suffix when ordering.
Where the Airtac 4V200 Solenoid Valve 4V230C-06-A Is Used
Mid-Stroke Holding Stations
Used in assembly fixtures where a cylinder must stop and hold a part precisely at mid-stroke for a secondary operation, with all ports blocked to prevent movement.
Vertical Gate Control
Controls a double-acting cylinder on a vertical gate or diverter, holding the gate in a safe, closed-center position if power is interrupted, preventing it from dropping.
Safety-Interlocked Clamping
In a clamping circuit, the closed center holds clamping force on a workpiece during an E-stop condition, ensuring the part remains secure until the system is reset.
Is the Airtac 4V200 Solenoid Valve 4V230C-06-A the Right Valve?
Choose the 4V230C-06A when your circuit requires a 5/3 closed-center function on a 1/8-inch ported base. This valve is a step up in flow from the 4V100 series (Cv 0.6) and is correctly sized for mid-range double-acting cylinders. If your application demands higher flow for larger bores or faster cycle rates, consider moving to the 4V300 body with a Cv of 1.65.
For direct replacement, match all five points: the 4V200 body size, the 5/3 closed-center function, the 1/8-inch PT port, the AC220V terminal-box coil, and the terminal-style electrical entry. This valve can be used as a single unit or ganged on a manifold base for multi-cylinder control panels.
Quick checklist
- ✓ Required flow (Cv) for cylinder & speed
- ✓ Function: single / double / 5-3 center
- ✓ Coil voltage (DC24 / AC220 …)
- ✓ Port thread (M5 / 1/8 / 1/4 / 3/8 / 1/2)
- ✓ Single valve or manifold base?
Installation & Wiring Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 0.8 MPa operating pressure.
- check Match coil voltage to your controller output.
- check Use the manual override to test before powering.
- check Fit silencers or fittings to the exhaust ports.
- check Wiring by qualified personnel per AirTAC docs.
Airtac 4V200 Solenoid Valve 4V230C-06-A FAQ
With a Cv of 0.8 and an effective area of 13.6 mm², this 5/3 valve is well-matched to double-acting cylinders from approximately 32 mm to 50 mm bore. For smaller O20 mm cylinders, a 4V100 series valve (Cv 0.6) may be more economical.
The 4V230C-06A has a closed center, meaning all air paths are blocked at the spool's center position. When both solenoids are de-energised, the air is trapped in the cylinder, holding the piston and load in place. Note that this is not a safety-rated holding brake; for suspended loads, an additional mechanical brake or pilot-operated check valve is required.
