AirTAC 4V Series · 5/2-way Solenoid Valve

Airtac 4V300 Solenoid Valve 4V320-08-A

The AirTAC 4V300 Solenoid Valve 4V320-08-A is a genuine 5/2-way double solenoid (memory) solenoid valve with PT1/4 ports and an effective area of 28.0 mm² (Cv 1.65). It is an internally piloted spool valve that directs compressed air to double-acting cylinders and actuators.

  • Valve type5/2-way
  • FunctionDouble solenoid (memory)
  • Port sizePT1/4
  • Effective area28.0 mm²
  • Flow (Cv)1.65
  • Series4V300
$58.12 $65.62Save 11% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every 4V320-08 stroke, mounting and version on one page All 4V320-08 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac 4V300 Solenoid Valve 4V320-08-A

The AirTAC 4V320-08A is a 5/2-way double-solenoid pneumatic directional valve built on the 4V300 body, directing compressed air to double-acting cylinders and rotary actuators. Its defining characteristic is a memory spool: a momentary pulse to either coil shifts the valve, and the spool stays in that last commanded position even when power is removed—no holding current required. This AC220V terminal-box model delivers a coil power of 4.5 VA and a response time of 0.05 s or below.

With an effective area of 28.0 mm² (Cv 1.65, catalog figure for the 4V310-10) and a maximum cycling frequency of 4 cycles per second, it comfortably drives medium-bore cylinders in the ~O50-80 mm range. The 1/4-inch PT (Rc) threaded ports keep the plumbing compact, while the IP65-rated aluminum-alloy body and integral manual override make it a robust choice for general industrial automation where the last state must be preserved through an E-stop or power cycle.

Airtac 4V300 Solenoid Valve 4V320-08-A Technical Specifications

ModelAirtac 4V300 Solenoid Valve 4V320-08-A
Series4V300 solenoid valve (spool type)
Valve type5/2-way
FunctionDouble solenoid (memory)
Port sizePT1/4
Exhaust portPT1/4
Effective area (Cv)28.0 mm² (Cv 1.65)
FluidAir (filtered by 40µm element)
Pilot typeInternal / external pilot
Operating pressure0.15 – 0.8 MPa
Proof pressure1.2 MPa
Max frequency4 cycle/sec
Response time≤ 0.05 s (activating)
Temperature-20 to +70 °C
Body materialAluminum alloy
Weight400 g

Specifications follow the official AirTAC 4V series datasheet. Lubrication not required. Confirm coil voltage and thread (PT / NPT / G) against the product label before wiring.

Flow & Coil Options

Effective area28.0 mm²
Flow coefficientCv 1.65
Response time≤ 0.05 s
Coil powerAC 4.5 VA · DC24V 3.0 W · DC12V 2.5 W
Protection / insulationIP65 (DIN40050), B-class
Voltage optionsDC24V, DC12V, AC110V, AC220V
Manual overrideYes (locking / non-locking)

Size the valve so effective area / Cv is not the bottleneck for your cylinder bore and speed. Undersized valves slow the actuator. Note 5/3 (center) versions have a smaller effective area than the 5/2 of the same body size.

Model Code: Airtac 4V300 Solenoid Valve 4V320-08-A

4VSolenoid valve, spool type, 4-series.
3Body size (4V300) — sets port & flow.
2Function: 1 = single 5/2, 2 = double 5/2, 3 = 5/3.
-08Port thread: M5 / 06=1/8" / 08=1/4" / 10=3/8" / 15=1/2".

Related: 4V310 (single), 4V320 (double), 4V330C/E/P (5/3 center). Add the voltage suffix when ordering.

Where the Airtac 4V300 Solenoid Valve 4V320-08-A Is Used

conveyor_belt

Material Handling Gates

Controls pneumatic gates and diverters on conveyor lines where the gate must stay in its last position if a line stop is triggered, preventing product misrouting.

precision_manufacturing

Clamp & Fixture Circuits

Operates double-acting clamps on CNC fixtures and welding jigs. The memory spool keeps the part clamped during a power interruption, avoiding workpiece shift, though a pilot check is advised for safety-critical holding.

factory

Pulse-Controlled Press Feeders

Directs a double-acting feed cylinder on a stamping press where a short electrical pulse advances the stroke and the valve holds position until the return pulse, simplifying the PLC logic.

Is the Airtac 4V300 Solenoid Valve 4V320-08-A the Right Valve?

Choose the 4V320-08A when your circuit needs a 5/2 valve that remembers its last position without continuous electrical power—this avoids heat build-up in the coil and saves energy. For a smaller cylinder (below O50 mm), stepping down to the 4V200 series (Cv ~1.0) often yields a more responsive and economical match; for large-bore cylinders above O80 mm, the 4V400 body (Cv 2.82) provides the necessary flow. If your application requires the cylinder to stop and hold at mid-stroke with all ports blocked, consider a 5/3 closed-center model (4V330C) instead.

When replacing an existing valve, match five points: the 4V300 body size, the double-solenoid (20) function, the 1/4-inch port and PT thread, the AC220V coil voltage, and the terminal-box electrical entry. This valve can be mounted individually or on a common manifold base to build a compact multi-valve station.

AirtacDistr lists every 4V320-08 order code with its price on one page at https://airtacdistr.com/products/airtac-4v320-08-solenoid-valve

Quick checklist

  • ✓ Required flow (Cv) for cylinder & speed
  • ✓ Function: single / double / 5-3 center
  • ✓ Coil voltage (DC24 / AC220 …)
  • ✓ Port thread (M5 / 1/8 / 1/4 / 3/8 / 1/2)
  • ✓ Single valve or manifold base?
Ask an Engineer

Installation & Wiring Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 0.8 MPa operating pressure.
  • check Match coil voltage to your controller output.
  • check Use the manual override to test before powering.
  • check Fit silencers or fittings to the exhaust ports.
  • check Wiring by qualified personnel per AirTAC docs.

Airtac 4V300 Solenoid Valve 4V320-08-A FAQ

With an effective area of 28.0 mm² (Cv 1.65, catalog figure for the 4V310-10), it is well matched to double-acting cylinders with a bore of approximately 50 to 80 mm. It provides sufficient flow for crisp actuation at a maximum frequency of 4 cycles per second.

Yes. As a double-solenoid memory valve, the spool remains in the position it was last pulsed to by friction and balanced pressure, with no spring return and no holding current. It is not magnetically latched. For suspended loads, add an external pilot-operated check valve.
