Airtac ACE Compact Cylinder ACE100X100S
The AirTAC Airtac ACE Compact Cylinder ACE100X100S is a genuine double acting ISO 21287 compact air cylinder with a Ø100mm bore and 100mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ100 mm
- Stroke100 mm
- Port size1/4"
- Acting typeDouble acting
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACE Compact Cylinder ACE100X100S
This AirTAC ACE100X100S is a double acting compact cylinder built to ISO 21287, with a hard-anodized aluminium body and a hard-chrome plated S45C steel rod. At 0.5 MPa it delivers 3927 N of push force and 3769.9 N of pull force, making it a strong choice for medium-heavy automation tasks.
Its short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it fits into tight guarding and gantry layouts. With the optional -S magnet fitted, you can mount CMSE or DMSE reed and solid-state switches for position sensing. For real work, plan on about 2356 N (0.6 times the push force) as a safe working load, which equals lifting roughly 240 kg vertically with a 2:1 safety margin.
Airtac ACE Compact Cylinder ACE100X100S Technical Specifications
| Model | Airtac ACE Compact Cylinder ACE100X100S |
|---|---|
| Series | ACE compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3770 N |
| 0.7 MPa | 5498 N | 5278 N |
| Max (@1.0 MPa) | 801 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac ACE Compact Cylinder ACE100X100S
| ACE | ISO 21287 compact cylinder (double-acting). |
|---|---|
| 100 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac ACE Compact Cylinder ACE100X100S Is Used
Press Platen
Use in a small press platen to apply 3927 N of clamping force at 0.5 MPa for stamping or forming thin metal parts.
Conveyor Stop Gate
Actuate a stop gate on a packaging conveyor, where the 100 mm stroke and 3769.9 N pull force retract the gate quickly to release products.
Machine Guard Door
Drive a sliding machine guard door on a CNC lathe, using the compact body to fit within the machine enclosure and the 3927 N push to move the heavy door.
Is the Airtac ACE Compact Cylinder ACE100X100S the Right Cylinder?
When sizing, compare this 100 mm bore with the 80 mm bore (2513.3 N push at 0.5 MPa) for lighter loads, or step up to the 125 mm bore (6135.9 N push at 0.5 MPa) if you need more force. The 100 mm stroke is standard for this bore, and the 1/4" port suits typical shop air supplies. Remember, a plain ACE does not hold position when air is lost; for holding a load, add a rod lock or pilot check valve.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac ACE Compact Cylinder ACE100X100S FAQ
At 0.5 MPa, the push force is 3927 N and the pull force is 3769.9 N. At 0.7 MPa, push is 5497.8 N and pull is 5277.9 N. The theoretical maximum force is 800.9 kgf at 1.0 MPa. The operating pressure range is 0.15-1.0 MPa (22-145 psi).
The ACE100X100S has a short body that saves about 50% of the mounting length compared to an ISO 15552 profile cylinder, which is ideal for tight spaces. It uses a fixed TPU bumper at both ends to absorb end-of-stroke impact, not an adjustable cushion. The optional -S magnet allows mounting CMSE or DMSE sensors for position feedback.
