Airtac ACE Compact Cylinder ACE100X110
The AirTAC Airtac ACE Compact Cylinder ACE100X110 is a genuine double acting ISO 21287 compact air cylinder with a Ø100mm bore and 110mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ100 mm
- Stroke110 mm
- Port size1/4"
- Acting typeDouble acting
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACE Compact Cylinder ACE100X110
This AirTAC ACE100X110 is a double acting compact cylinder with a 100 mm bore and 110 mm stroke, delivering 3927 N of push force at 0.5 MPa. Its hard-anodized aluminium body and S45C hard-chrome plated rod are built for demanding cycles, and the fixed TPU bumper at both ends absorbs end-of-stroke impact without the need for adjustment.
At 0.5 MPa, the pull force is 3769.9 N, and the theoretical maximum thrust reaches 800.9 kgf at 1.0 MPa. For a real application, plan for a safe working load of about 2356 N (roughly 240 kg) at 0.5 MPa, which gives a comfortable margin for dynamic loads. The ISO 21287 short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, making it ideal for tight machine frames and guarding where space is at a premium.
Airtac ACE Compact Cylinder ACE100X110 Technical Specifications
| Model | Airtac ACE Compact Cylinder ACE100X110 |
|---|---|
| Series | ACE compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 110 mm |
| Acting type | Double acting |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3770 N |
| 0.7 MPa | 5498 N | 5278 N |
| Max (@1.0 MPa) | 801 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac ACE Compact Cylinder ACE100X110
| ACE | ISO 21287 compact cylinder (double-acting). |
|---|---|
| 100 | Bore size in mm. |
| ×110 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac ACE Compact Cylinder ACE100X110 Is Used
Press Fit Station
Use the 3927 N push to press bushings or bearings into housings on an assembly line, with the short body fitting under a guarding panel.
Conveyor Stop Gate
Actuate a stop gate on a heavy package conveyor, where the 110 mm stroke clears the product path and the 3769.9 N pull retracts it quickly.
Clamping Fixture
Clamp a large metal part in a CNC fixture, using the 5497.8 N push at 0.7 MPa to hold it securely during machining, with the compact body leaving room for tooling.
Is the Airtac ACE Compact Cylinder ACE100X110 the Right Cylinder?
For a lighter duty, consider the ACE80X110 with 2513.3 N push at 0.5 MPa, or step up to the ACE125X110 for 6135.9 N push if you need more force. This ACE100X110 is a balanced choice for medium-to-heavy automation tasks. Since this model has no -S code, it has no magnet, so CMSE or DMSE sensors cannot be mounted; order the -S version if you need position sensing. The female rod thread is M12x1.75, and the port is 1/4" PT, so check your fittings and mounting brackets (FA, FB, LB, CA, CB, CR, SDB, FTC) against the ISO 21287 face.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac ACE Compact Cylinder ACE100X110 FAQ
At 0.5 MPa, the push force is 3927 N and the pull force is 3769.9 N. At 0.7 MPa, push is 5497.8 N and pull is 5279.9 N. The theoretical maximum force is 800.9 kgf at 1.0 MPa. The operating pressure range is 0.15-1.0 MPa (22-145 psi), with a proof pressure of 1.5 MPa (215 psi).
The ACE100X110 has a short body that saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it fits into tight spaces like gantries or under machine guards. It uses a fixed TPU bumper at both ends to absorb impact, and the hard-anodized aluminium body resists wear. The optional -S magnet is needed for CMSE or DMSE sensors; this model without -S has no magnet.
