Airtac ACE Compact Cylinder ACE100X110B
The AirTAC Airtac ACE Compact Cylinder ACE100X110B is a genuine double acting ISO 21287 compact air cylinder with a Ø100mm bore and 110mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ100 mm
- Stroke110 mm
- Port size1/4"
- Acting typeDouble acting
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACE Compact Cylinder ACE100X110B
This AirTAC ACE100X110B is a double acting compact cylinder built to ISO 21287, with a 100 mm bore and a 110 mm stroke. Its hard-anodized aluminium body is about 50% shorter than an ISO 15552 profile cylinder, which lets it fit into tight machine frames and guarding where a full-length unit will not. The S45C steel rod is hard-chrome plated and has a male thread (B code) for direct coupling to a load.
At 0.5 MPa this bore delivers 3927 N of push force, which translates to a practical vertical lift of about 240 kg when you apply a 2:1 safety margin. The fixed TPU bumper at each end absorbs impact energy, but it is not a lock - if air pressure is lost, the rod will drift, so use a rod lock or pilot check valve for any held position. The 1/4" port accepts standard fittings, and the operating range is 0.15-1.0 MPa (22-145 psi) with speeds from 30-500 mm/s.
Airtac ACE Compact Cylinder ACE100X110B Technical Specifications
| Model | Airtac ACE Compact Cylinder ACE100X110B |
|---|---|
| Series | ACE compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 110 mm |
| Acting type | Double acting |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3770 N |
| 0.7 MPa | 5498 N | 5278 N |
| Max (@1.0 MPa) | 801 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac ACE Compact Cylinder ACE100X110B
| ACE | ISO 21287 compact cylinder (double-acting). |
|---|---|
| 100 | Bore size in mm. |
| ×110 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac ACE Compact Cylinder ACE100X110B Is Used
Press Ram for Small Stamping
Use this 100 mm bore cylinder to drive a small press ram for stamping or embossing metal parts up to 240 kg of force, where the compact body fits between die set guide pillars.
Conveyor Stop Gate
Mount this cylinder vertically to raise and lower a stop gate on a packaging conveyor line. The 110 mm stroke lifts the gate clear of the product path, and the fixed bumper handles the end-of-stroke impact.
Clamping Fixture for Machining
In a CNC machining cell, this cylinder can clamp a workpiece against a fixture with 3927 N of force. The short body allows the clamp to be mounted close to the spindle, saving valuable workspace.
Is the Airtac ACE Compact Cylinder ACE100X110B the Right Cylinder?
For a lighter duty application, the ACE80X110 offers 2513 N push at 0.5 MPa, while stepping up to the ACE125X110 gives you 6135.9 N push at the same pressure. This 100 mm bore sits in the middle of the range, providing a good balance of force and footprint for medium-sized automation cells. Since this model has no -S code, there is no magnet fitted, so you cannot mount CMSE or DMSE sensors on it; order the ACE100X110SB variant if you need position sensing. The male rod thread (B) simplifies attaching a clevis or rod end, and you can choose from FA/FB flange, LB foot, CA/CB clevis, CR, SDB pivot, or FTC brackets to match your mounting pattern.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac ACE Compact Cylinder ACE100X110B FAQ
At 0.5 MPa, the push force is 3927 N and the pull force is 3769.9 N. At 0.7 MPa, push is 5497.8 N and pull is 5277.9 N. The theoretical maximum force at 1.0 MPa is 800.9 kgf. These figures are based on the official AirTAC datasheet for the 100 mm bore.
The ACE is an ISO 21287 compact cylinder, so its body is about 50% shorter than an ISO 15552 profile cylinder, making it ideal for tight spaces. This specific model has no -S code, meaning it has no magnet, so you cannot mount CMSE or DMSE sensors on it. You would need to order the ACE100X110SB version to get the optional magnet for sensor feedback.
