Airtac ACE Compact Cylinder ACE100X110SB
The AirTAC Airtac ACE Compact Cylinder ACE100X110SB is a genuine double acting ISO 21287 compact air cylinder with a Ø100mm bore and 110mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ100 mm
- Stroke110 mm
- Port size1/4"
- Acting typeDouble acting
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACE Compact Cylinder ACE100X110SB
This AirTAC ACE100X110SB is a double acting ISO 21287 compact cylinder with a 100 mm bore and 110 mm stroke. Its hard-anodized aluminium body is about 50% shorter than an ISO 15552 profile cylinder, letting it fit into tight machine guarding and compact jigs where a full-length cylinder will not.
With a 3927 N push force at 0.5 MPa, this unit can lift about 240 kg vertically with a 2:1 safety margin. The male rod thread (B code) simplifies mounting linkages, while the optional -S magnet is fitted here, enabling CMSE or DMSE reed and solid-state switches for position sensing.
Airtac ACE Compact Cylinder ACE100X110SB Technical Specifications
| Model | Airtac ACE Compact Cylinder ACE100X110SB |
|---|---|
| Series | ACE compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 110 mm |
| Acting type | Double acting |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3770 N |
| 0.7 MPa | 5498 N | 5278 N |
| Max (@1.0 MPa) | 801 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac ACE Compact Cylinder ACE100X110SB
| ACE | ISO 21287 compact cylinder (double-acting). |
|---|---|
| 100 | Bore size in mm. |
| ×110 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac ACE Compact Cylinder ACE100X110SB Is Used
Fixture Clamping
Mount this ACE100X110SB on a CNC fixture to clamp large aluminium workpieces with 3927 N of force at 0.5 MPa, holding parts securely during milling operations.
Carton Compression
Use in a packaging line to compress bulky cartons before strapping. The 110 mm stroke handles tall products, while the compact body fits under existing conveyor guards.
Press Ram
In a small press, this cylinder delivers 5497 N push at 0.7 MPa for stamping thin sheet metal parts. The male rod thread allows direct attachment of a custom die plate.
Is the Airtac ACE Compact Cylinder ACE100X110SB the Right Cylinder?
For lighter duty in the same compact footprint, the ACE80X110 offers 2513 N push at 0.5 MPa, while stepping up to the ACE125X110 provides 6135 N push. This 100 mm bore model suits medium-to-heavy clamping and pressing applications where space is limited. The fixed TPU bumper absorbs end-of-stroke impact but does not hold a load; use a rod lock or pilot check valve if position must be maintained when air pressure is lost.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac ACE Compact Cylinder ACE100X110SB FAQ
At 0.5 MPa, push is 3927 N and pull is 3769.9 N. At 0.7 MPa, push is 5497.8 N and pull is 5277.9 N. Theoretical maximum force is 800.9 kgf at 1.0 MPa.
Yes, this specific model includes the optional -S magnet, so you can mount CMSE or DMSE reed and solid-state switches. The magnet is not standard on every ACE cylinder; it must be specified with the -S code. The fixed TPU bumper absorbs end-of-stroke energy but does not provide adjustable cushioning.
