Airtac ACE Compact Cylinder ACE100X150SBH
The AirTAC Airtac ACE Compact Cylinder ACE100X150SBH is a genuine double acting ISO 21287 compact air cylinder with a Ø100mm bore and 150mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ100 mm
- Stroke150 mm
- Port size1/4"
- Acting typeDouble acting
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACE Compact Cylinder ACE100X150SBH
This AirTAC ACE100X150SBH is a double acting ISO 21287 compact cylinder that delivers a 3927 N push force at 0.5 MPa, with a matching pull of 3769.9 N. Its short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it fits into tight automation frames where a full-length cylinder will not.
With the optional -S magnet fitted, this model works with CMSE or DMSE reed and solid-state switches for reliable position sensing. The hard-anodized aluminium body and S45C hard-chrome plated rod resist wear in continuous cycling. For a real-world load, plan on about 240 kg of safe vertical lifting at 0.5 MPa, which is roughly 0.6 times the rated push force, giving you a practical margin for jigs and workpieces.
Airtac ACE Compact Cylinder ACE100X150SBH Technical Specifications
| Model | Airtac ACE Compact Cylinder ACE100X150SBH |
|---|---|
| Series | ACE compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 150 mm |
| Acting type | Double acting |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3770 N |
| 0.7 MPa | 5498 N | 5278 N |
| Max (@1.0 MPa) | 801 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac ACE Compact Cylinder ACE100X150SBH
| ACE | ISO 21287 compact cylinder (double-acting). |
|---|---|
| 100 | Bore size in mm. |
| ×150 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac ACE Compact Cylinder ACE100X150SBH Is Used
Automotive Assembly Jig
Use this cylinder to clamp a car door panel in a welding fixture. The 3927 N push at 0.5 MPa holds the part firmly, while the compact body fits between the frame rails, and the -S magnet lets a sensor confirm the clamp is closed.
Carton Ejector
In a packaging line, this cylinder pushes filled cartons off a conveyor onto a pallet. The 150 mm stroke clears the full carton width, and the 3769.9 N pull retracts the rod quickly for the next cycle, running at speeds up to 500 mm/s.
Pallet Stops
Mount this cylinder at a pallet transfer station to raise a stop that halts incoming pallets. The 3927 N push handles heavy loads, and the compact ISO 21287 body mounts under the conveyor deck without protruding into the aisle.
Is the Airtac ACE Compact Cylinder ACE100X150SBH the Right Cylinder?
Choose this 100 mm bore model when you need a strong push of 3927 N at 0.5 MPa in a compact envelope. If your application demands less force, the 80 mm bore ACE80 delivers 2513.3 N push, while stepping up to the 125 mm bore ACE125 gives you 6135.9 N push for heavier work. The 150 mm stroke fits standard fixtures, and the male rod thread (B) simplifies mounting with rod-end accessories.
Since this unit carries the optional -S magnet, you can add CMSE or DMSE sensors for position feedback. Remember that a plain ACE does not hold its position when air pressure is lost; for holding a load, use a rod lock or pilot check valve. The 1/4" port matches standard fittings, and the fixed TPU bumper at both ends absorbs end-of-stroke impacts.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac ACE Compact Cylinder ACE100X150SBH FAQ
At 0.5 MPa, the push force is 3927 N and the pull force is 3769.9 N. At 0.7 MPa, push is 5497.8 N and pull is 5277.9 N. The theoretical maximum force is 800.9 kgf at 1.0 MPa. These figures are based on the 100 mm bore and 20 mm rod.
The ACE100X150SBH has a short body that saves about 50% of the mounting length of an ISO 15552 profile cylinder, making it ideal for tight spaces. It uses a fixed TPU bumper at both ends to absorb impact, and the optional -S magnet allows CMSE or DMSE switches for position sensing. The operating pressure range is 0.15-1.0 MPa (22-145 psi), with speeds from 30-500 mm/s.
