Airtac ACED Double-acting Compact Cylinder ACED100X100SB
The AirTAC Airtac ACED Double-acting Compact Cylinder ACED100X100SB is a genuine double acting, double rod ISO 21287 compact air cylinder with a Ø100mm bore and 100mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ100 mm
- Stroke100 mm
- Port size1/4"
- Acting typeDouble acting, double rod
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACED Double-acting Compact Cylinder ACED100X100SB
A double acting, double-rod compact cylinder built to ISO 21287, the ACED100X100SB pushes a 100 mm piston through a 100 mm stroke with a 20 mm rod leaving BOTH covers. Because both strokes work on the rod-side area, output is a matched 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa in each direction - no push/pull imbalance to design around. The male rod thread (B code) suits external rod accessories, and the fitted -S magnet lets CMSE or DMSE switches report end positions.
The short ISO 21287 body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so a 100 mm bore fits presses, clamps and lift stations where a full-length profile body will not. As a working rule, plan on roughly 2262 N (about 60% of rating) for real work at 0.5 MPa, which corresponds to lifting about 115 kg vertically with a 2:1 margin. A fixed TPU bumper at each end absorbs end-of-stroke shock, and the hard-anodized aluminium body with S45C hard-chrome rod runs 0.15-1.0 MPa (22-145 psi) at 30-500 mm/s.
Airtac ACED Double-acting Compact Cylinder ACED100X100SB Technical Specifications
| Model | Airtac ACED Double-acting Compact Cylinder ACED100X100SB |
|---|---|
| Series | ACED compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 100 mm |
| Acting type | Double acting, double rod |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3770 N |
| 0.7 MPa | 5278 N |
| Max (@1.0 MPa) | 769 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used).
Model Code: Airtac ACED Double-acting Compact Cylinder ACED100X100SB
| ACED | ISO 21287 compact cylinder (double-rod). |
|---|---|
| 100 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac ACED Double-acting Compact Cylinder ACED100X100SB Is Used
Baling press platen drive
The symmetric 3769.9 N force both ways suits a small scrap or can baler where the platen must compact and retract with equal authority inside a short frame.
Pallet stacker lift mast
A through-rod driving a chain sheave gives a balanced lift for about 115 kg pallet loads vertically with a 2:1 margin, and the 100 mm stroke matches a compact mast.
Reciprocating conveyor pusher
Equal force in both directions keeps cartons pushed and returned at the same speed on a packaging line, with CMSE switches on the fitted magnet confirming each stroke.
Is the Airtac ACED Double-acting Compact Cylinder ACED100X100SB the Right Cylinder?
At 3769.9 N per side at 0.5 MPa, the 100 mm bore sits well above the 80 mm bore (2356.2 N) and below the 125 mm bore (5890.5 N) - step down if force is generous, up if you need more than about 3.7 kN. Remember the piston drifts if air is lost; add a rod lock or pilot check valve for a held load. FA/FB flange and LB foot brackets bolt to the ISO 21287 face, and the fitted magnet means CMSE / DMSE switches mount without reordering. Air must be filtered to 40 um; proof pressure is 1.5 MPa (215 psi) and the temperature range is -20 to +70 C.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac ACED Double-acting Compact Cylinder ACED100X100SB FAQ
Yes - the double-rod design works on the rod-side area for both strokes, so output is 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa in each direction, with a maximum of 768.8 kgf at 1.0 MPa. Operating range is 0.15-1.0 MPa (22-145 psi), speed 30-500 mm/s, and the 100 mm stroke is within the 300 mm standard limit for this bore.
The ISO 21287 short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, freeing space in tight gantries and guards. This model carries the optional -S magnet, so CMSE or DMSE reed or solid-state switches can be clipped onto the body slot for end-of-stroke signalling, and a fixed TPU bumper at each end absorbs the end-of-stroke shock.
