Airtac ACED Double-acting Compact Cylinder ACED100X10S
The AirTAC Airtac ACED Double-acting Compact Cylinder ACED100X10S is a genuine double acting, double rod ISO 21287 compact air cylinder with a Ø100mm bore and 10mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ100 mm
- Stroke10 mm
- Port size1/4"
- Acting typeDouble acting, double rod
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACED Double-acting Compact Cylinder ACED100X10S
The ACED100X10S is a double acting, double-rod compact cylinder built to the ISO 21287 short-body format. With a 100 mm bore and a 10 mm stroke, it delivers 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa in BOTH directions, because a 20 mm rod exits each cover and both strokes work on the rod-side area. Ports are 1/4" and the female rod thread is M12x1.75.
The hard-anodized aluminium body with an S45C hard-chrome plated rod runs on air filtered to 40 um at 0.15-1.0 MPa (22-145 psi), 30-500 mm/s, and -20 to +70 C. Its short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it slots into presses and clamping fixtures where a full-length body cannot. The through-rod resists rotation and side load, and the rear rod can carry a sensor flag. This -S version carries the optional magnet, so CMSE / DMSE switches mount directly. Plan on roughly 2262 N of real work at 0.5 MPa, which lifts about 192 kg vertically with a 2:1 margin.
Airtac ACED Double-acting Compact Cylinder ACED100X10S Technical Specifications
| Model | Airtac ACED Double-acting Compact Cylinder ACED100X10S |
|---|---|
| Series | ACED compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 10 mm |
| Acting type | Double acting, double rod |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3770 N |
| 0.7 MPa | 5278 N |
| Max (@1.0 MPa) | 769 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used).
Model Code: Airtac ACED Double-acting Compact Cylinder ACED100X10S
| ACED | ISO 21287 compact cylinder (double-rod). |
|---|---|
| 100 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac ACED Double-acting Compact Cylinder ACED100X10S Is Used
Short-stroke press station
The 10 mm stroke and 3769.9 N both-ways force make this cylinder a compact punch or marking head on an aluminium fixture plate where every millimetre of length counts.
Reciprocating transfer carriage
A rod on each cover lets the through-rod drive a slider from either side with equal 5277.9 N at 0.7 MPa, keeping the carriage square without an anti-rotation guide.
Gantry part-present check
With the fitted magnet and a DMSE switch, the rear rod carries a flag so the PLC confirms clamp position on an automotive welding fixture in under 10 mm of travel.
Is the Airtac ACED Double-acting Compact Cylinder ACED100X10S the Right Cylinder?
At 3769.9 N per stroke at 0.5 MPa, the 100 mm bore suits heavy clamping and short-stroke pressing. Step down to the 63 mm bore (1458.1 N at 0.5 MPa) for lighter loads, or up to 125 mm (5890.5 N at 0.5 MPa) when force headroom matters. Remember the piston drifts if air is lost - add a rod lock or pilot check valve where a load must stay put. FA/FB flanges, LB feet and FTC brackets bolt to the ISO 21287 face, and the fitted magnet accepts CMSE / DMSE switches for end-of-stroke signalling.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac ACED Double-acting Compact Cylinder ACED100X10S FAQ
Because it is a double-rod cylinder, force is identical on both strokes: 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa (rod-side area, 100 mm bore). Peak force at 1.0 MPa is 768.8 kgf. Operating range is 0.15-1.0 MPa (22-145 psi) with a 1.5 MPa (215 psi) proof pressure, and speed spans 30-500 mm/s.
The ISO 21287 body is about 50% shorter in mounting length than an ISO 15552 profile cylinder, and a fixed TPU bumper at each end absorbs piston impact - it is not adjustable and never holds a load. Mounting uses FA/FB flanges, LB feet or FTC brackets on the standard face, and this -S model carries the optional magnet so CMSE / DMSE switches can be clipped onto the body slot.
