Airtac ACED Double-acting Compact Cylinder ACED100X120SB
The AirTAC Airtac ACED Double-acting Compact Cylinder ACED100X120SB is a genuine double acting, double rod ISO 21287 compact air cylinder with a Ø100mm bore and 120mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ100 mm
- Stroke120 mm
- Port size1/4"
- Acting typeDouble acting, double rod
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACED Double-acting Compact Cylinder ACED100X120SB
A double acting compact cylinder built to ISO 21287, the ACED100X120SB pushes a 100 mm bore through a 120 mm stroke with a rod leaving BOTH covers, so thrust is identical on the out-stroke and the return: 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa in either direction. Air supply is 0.15-1.0 MPa (22-145 psi), speed range 30-500 mm/s, and a fixed TPU bumper sits at each end of travel.
The through-rod is the working advantage here: the 20 mm hard-chrome S45C rod resists rotation and side load, gives a symmetric mount on both faces, and the rear rod can carry a sensor flag on a press fixture. This S-code model carries the optional -S magnet, so CMSE / DMSE switches read position directly on the hard-anodized aluminium body. For real-world sizing, keep continuous work near 2260 N at 0.5 MPa, which corresponds to lifting roughly 192 kg vertically with a 2:1 margin.
Airtac ACED Double-acting Compact Cylinder ACED100X120SB Technical Specifications
| Model | Airtac ACED Double-acting Compact Cylinder ACED100X120SB |
|---|---|
| Series | ACED compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 120 mm |
| Acting type | Double acting, double rod |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3770 N |
| 0.7 MPa | 5278 N |
| Max (@1.0 MPa) | 769 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used).
Model Code: Airtac ACED Double-acting Compact Cylinder ACED100X120SB
| ACED | ISO 21287 compact cylinder (double-rod). |
|---|---|
| 100 | Bore size in mm. |
| ×120 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac ACED Double-acting Compact Cylinder ACED100X120SB Is Used
Bench-top press and forming station
3769.9 N at 0.5 MPa in both directions suits staking, swaging and light forming on aluminium brackets, with the 120 mm stroke clearing part load and unload in a compact frame.
Symmetric clamp fixture on a machining line
A rod on each face lets one cylinder clamp a cast housing from both sides with equal force, and the through-rod resists the side load of off-center clamping.
Pallet transfer pusher in a warehouse cell
The 100 mm bore moves loaded pallet cages at 30-500 mm/s, and the rear rod carries a CMSE switch flag (magnet fitted on this -S model) for end-of-stroke confirmation.
Is the Airtac ACED Double-acting Compact Cylinder ACED100X120SB the Right Cylinder?
At 100 mm bore this is a heavy-thrust size: 3769.9 N at 0.5 MPa both ways. Step down to the 80 mm bore (2356.2 N at 0.5 MPa) if the press or clamp load is lighter, or up to 125 mm (5890.5 N at 0.5 MPa) when you need the full 1200 kgf class. The 120 mm stroke sits well inside the 300 mm maximum standard stroke for this bore, so it ships as a standard build. The male rod thread is M12x1.25 per the B code, the port is 1/4" PT, and FA/FB flange, LB foot or FTC brackets bolt straight to the ISO 21287 face. Note that a plain double-rod cylinder drifts when air is lost - add a rod lock or pilot check if the load must stay put.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac ACED Double-acting Compact Cylinder ACED100X120SB FAQ
Because a rod exits both covers, output is equal both ways: 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa on the out-stroke and the return alike. At the full 1.0 MPa rating the cylinder reaches about 768.8 kgf. Keep continuous duty near 2260 N, which is roughly a 192 kg vertical lift with a 2:1 margin.
The S means the optional -S magnet is fitted on this unit, so CMSE / DMSE reed or solid-state switches can be mounted anywhere along the hard-anodized aluminium body. The ISO 21287 short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, and the fixed TPU bumper at each end absorbs end-of-stroke energy. Operating range is 0.15-1.0 MPa (22-145 psi), -20 to +70 C.
