Airtac ACED Double-acting Compact Cylinder ACED100X15
$130.50
Regular price
$138.00
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACED100X15
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with ISO 21287 standard for superior interchangeability of mounting dimensions;
2. Threaded connection between cylinder barrel and end caps ensures structural integrity and maintenance convenience;
3. Precision-machined bore with hard anodized surface treatment enhances wear resistance and durability;
4. Specially designed bidirectional sealing structure on piston enables compact dimensions and integrated oil reservoir functionality;
5. Space-saving design reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided sensor slots on barrel facilitate streamlined sensor integration;
7. Integrated shock absorber effectively absorbs residual energy from high-speed operation and mechanical rotation;
8. Multiple standardized mounting accessories available for flexible configuration.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACED
Installation notes:
Ensure proper alignment of dual rods during mounting. Use alignment couplers when connecting to loads.
Lubricate with ISO VG32 hydraulic oil if operating below -10℃. Adjust cushion screws in 1/4-turn increments
for optimal deceleration. Avoid side loads exceeding 30N.
2. Threaded connection between cylinder barrel and end caps ensures structural integrity and maintenance convenience;
3. Precision-machined bore with hard anodized surface treatment enhances wear resistance and durability;
4. Specially designed bidirectional sealing structure on piston enables compact dimensions and integrated oil reservoir functionality;
5. Space-saving design reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided sensor slots on barrel facilitate streamlined sensor integration;
7. Integrated shock absorber effectively absorbs residual energy from high-speed operation and mechanical rotation;
8. Multiple standardized mounting accessories available for flexible configuration.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACED
AirTAC ACED100X15 Double Rod Compact Cylinder Specifications
- Model: ACED100X15
- Type: Double-acting, dual rod compact cylinder
- Bore size: Ø100mm
- Stroke: 15mm
- Operating pressure: 0.1–0.9 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Mounting types: MF1 (front flange), MB1 (rear flange), or foot mounting
- Port size: G1/8 or 1/4-NPT (optional)
- Max piston speed: 500 mm/s
- Weight: Approximately 2.8 kg (excluding accessories)
- Dimensions: 180mm(L) × 100mm(W) × 100mm(H) (at mid-stroke position)
- Rod thread: M10×1.25 (both ends)
- Protection rating: IP54 (standard)
High-precision dual rod cylinder featuring symmetrical force output and space-saving design. The twin-rod configuration ensures synchronized movement in both extension/retraction directions, ideal for applications requiring balanced force distribution. Enhanced with wear-resistant seals and corrosion-resistant coatings for industrial environments.
Typical Applications:
- Precision clamping fixtures in CNC machining centers
- Vertical lifting mechanisms in packaging lines
- Parallel gripper actuation in robotic systems
- Position adjustment in semiconductor manufacturing
- Gate control in injection molding machines
Installation notes:
Ensure proper alignment of dual rods during mounting. Use alignment couplers when connecting to loads.
Lubricate with ISO VG32 hydraulic oil if operating below -10℃. Adjust cushion screws in 1/4-turn increments
for optimal deceleration. Avoid side loads exceeding 30N.
Performance Features:
- Low friction design achieves ≤0.15 dynamic friction coefficient
- Tolerance: ±0.5mm on stroke length under full load
- Repeat positioning accuracy: ±0.1mm
- Minimum operating frequency: 10 cycles/minute (continuous duty)
| Property | Property Value |
|---|---|
| sku | ACED100X15 |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | Internal Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | <15mm> |
