Airtac ACED Double-acting Compact Cylinder ACED100X150B
$176.30
Regular price
$183.80
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACED100X150B
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with ISO 21287 standard for superior interchangeability of mounting dimensions;
2. Threaded connection between cylinder barrel and end caps ensures structural integrity and maintenance convenience;
3. Precision-machined bore with hard anodized surface treatment enhances wear resistance and durability;
4. Specially designed bidirectional sealing structure on piston enables compact dimensions and integrated oil reservoir functionality;
5. Space-saving design reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided sensor slots on barrel facilitate streamlined sensor integration;
7. Integrated shock absorber effectively absorbs residual energy from high-speed operation and mechanical rotation;
8. Multiple standardized mounting accessories available for flexible configuration.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACED
Installation tips:
Lubricate with ISO VG32 hydraulic oil before initial use.
Maintain 0.3-1mm clearance between rod ends and load connection.
For vertical mounting, install with piston rod facing downward to prevent sediment accumulation.
Avoid side load exceeding 30N.
Use with clean compressed air (ISO 8573-1:2010 class 3.4.3).
Maximum piston speed: 500 mm/s. Allow 15-minute run-in period at 0.3MPa for optimal seal performance.
2. Threaded connection between cylinder barrel and end caps ensures structural integrity and maintenance convenience;
3. Precision-machined bore with hard anodized surface treatment enhances wear resistance and durability;
4. Specially designed bidirectional sealing structure on piston enables compact dimensions and integrated oil reservoir functionality;
5. Space-saving design reduces installation footprint by up to 50% compared to ISO 15552 standard cylinders of equivalent bore size;
6. Triple-sided sensor slots on barrel facilitate streamlined sensor integration;
7. Integrated shock absorber effectively absorbs residual energy from high-speed operation and mechanical rotation;
8. Multiple standardized mounting accessories available for flexible configuration.
Category: Double Rod Cylinders | Brand: AirTAC | Series: ACED
AirTAC ACED100X150B Double Rod Compact Cylinder Specifications
- Model: ACED100X150B
- Type: Double rod compact cylinder (ISO 6432 standard)
- Bore size: Ø100 mm
- Stroke: 150 mm (customizable 25-500mm)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting: Basic type with foot mounting holes
- Port size: Rc1/4 (G1/4 optional)
- Piston rod material: Hard chrome-plated carbon steel
- Seal material: NBR (nitrile rubber)
- Rod ends: Double external threads (M16×1.5)
- Protection rating: IP65 (standard wiper design)
- Weight: 5.8 kg ±2% (excluding accessories)
- Dimensions: 250mm(L) × 110mm(W) × 110mm(H) (Cylinder body only)
- Max theoretical force: 785N @0.8MPa
High-rigidity compact cylinder featuring twin piston rods for balanced bidirectional force transmission. The anodized aluminum construction ensures corrosion resistance while maintaining lightweight properties. Integrated magnetic slot (optional sensor mounting) enables position feedback. Designed for 1 million+ cycle durability with <1mm/m anti-rotation accuracy.
Ideal Applications:
- Precision clamping fixtures in CNC machining centers
- Vertical lifting mechanisms for assembly robots
- Synchronized actuation in packaging conveyor systems
- Press-fit operations in automotive part manufacturing
- Material handling gates in warehouse automation
Installation tips:
Lubricate with ISO VG32 hydraulic oil before initial use.
Maintain 0.3-1mm clearance between rod ends and load connection.
For vertical mounting, install with piston rod facing downward to prevent sediment accumulation.
Avoid side load exceeding 30N.
Use with clean compressed air (ISO 8573-1:2010 class 3.4.3).
Maximum piston speed: 500 mm/s. Allow 15-minute run-in period at 0.3MPa for optimal seal performance.
| Property | Property Value |
|---|---|
| sku | ACED100X150B |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | G1/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 150mm |
