Airtac ACED Double-acting Compact Cylinder ACED100X150SB
The AirTAC Airtac ACED Double-acting Compact Cylinder ACED100X150SB is a genuine double acting, double rod ISO 21287 compact air cylinder with a Ø100mm bore and 150mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ100 mm
- Stroke150 mm
- Port size1/4"
- Acting typeDouble acting, double rod
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACED Double-acting Compact Cylinder ACED100X150SB
A double acting, double-rod ISO 21287 compact cylinder, the ACED100X150SB pushes a 100 mm piston through a 150 mm stroke with a rod leaving both covers. Because each side works on the rod-side area, output is identical in either direction: 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa, both ways. The male-threaded 20 mm rod (B code) bolts directly to tooling, and the through-rod resists rotation and side load while the rear rod can carry a sensor flag.
The hard-anodized aluminium body with an S45C hard-chrome-plated rod runs at 0.15-1.0 MPa (22-145 psi) and 30-500 mm/s, with a fixed TPU bumper at each end. Its short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it slots into presses and gantries where full-length bodies will not fit. As a planning figure, expect roughly 2262 N of real work at 0.5 MPa, which lifts about 192 kg vertically with a 2:1 margin. This -S model carries the optional magnet, so CMSE / DMSE switches mount straight on the body.
Airtac ACED Double-acting Compact Cylinder ACED100X150SB Technical Specifications
| Model | Airtac ACED Double-acting Compact Cylinder ACED100X150SB |
|---|---|
| Series | ACED compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 150 mm |
| Acting type | Double acting, double rod |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3770 N |
| 0.7 MPa | 5278 N |
| Max (@1.0 MPa) | 769 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used).
Model Code: Airtac ACED Double-acting Compact Cylinder ACED100X150SB
| ACED | ISO 21287 compact cylinder (double-rod). |
|---|---|
| 100 | Bore size in mm. |
| ×150 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac ACED Double-acting Compact Cylinder ACED100X150SB Is Used
Stamping die ejector
The symmetric 3769.9 N push and pull ejects formed steel panels from a die at equal speed, with the rear rod driving a scrap-detect sensor flag.
Pallet gate actuator
A warehouse palletizing line uses the through-rod to swing heavy safety gates both ways, the 192 kg vertical-lift equivalent covering the gate mass with margin.
Lift-and-press fixture
An automotive bracket press clamps with 2262 N of usable force at 0.5 MPa while CMSE switches on the fitted magnet confirm both end positions.
Is the Airtac ACED Double-acting Compact Cylinder ACED100X150SB the Right Cylinder?
At 3769.9 N per direction, this bore sits between the 80 mm frame (2356.2 N at 0.5 MPa) and the 125 mm frame (5890.5 N at 0.5 MPa); step down for lighter clamping, up for heavy stamping. The 150 mm stroke is well inside the 300 mm standard limit for bore 100, so no made-to-order build is needed. Remember the piston drifts if air is lost - add a rod lock or pilot check where a load must stay put. FA/FB flanges, LB feet and FTC brackets bolt to the ISO 21287 face, and I/Y rod knuckles suit the male thread.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac ACED Double-acting Compact Cylinder ACED100X150SB FAQ
Yes - the double-rod design means both strokes use the rod-side area, so output is equal either way: 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa, with a peak of 768.8 kgf at 1.0 MPa. Operating range is 0.15-1.0 MPa (22-145 psi), proof 1.5 MPa (215 psi), speed 30-500 mm/s, air filtered to 40 um.
The compact aluminium body saves about 50% of the mounting length of an ISO 15552 profile cylinder, freeing space in tight machine frames. The S in the code means the magnet is fitted, so CMSE or DMSE reed or solid-state switches mount in the body slots; models ordered without -S carry no magnet. A fixed TPU bumper at each end absorbs end-of-stroke impact.
