Airtac ACED Double-acting Compact Cylinder ACED100X160B
The AirTAC Airtac ACED Double-acting Compact Cylinder ACED100X160B is a genuine double acting, double rod ISO 21287 compact air cylinder with a Ø100mm bore and 160mm stroke, 1/4" air ports and a hard-anodized aluminium body. Its short compact envelope saves about 50% of the mounting length of an ISO 15552 profile cylinder.
- BoreØ100 mm
- Stroke160 mm
- Port size1/4"
- Acting typeDouble acting, double rod
- Rod threadM12×1.75
- CushionFixed TPU bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACED Double-acting Compact Cylinder ACED100X160B
A double acting compact cylinder built to ISO 21287, the ACED100X160B pushes a 100 mm bore through a 160 mm stroke with a rod leaving BOTH covers. Because each side sees the rod-side area, output is identical in either direction: 3769.9 N at 0.5 MPa and 5277.9 N at 0.7 MPa, with a peak of 768.8 kgf at 1.0 MPa. The male rod thread from the B code bolts straight to your tooling, and the through-rod resists rotation and side load while the rear rod can carry a sensor flag on a fixture.
The hard-anodized aluminium body with an S45C hard-chrome rod runs on air filtered to 40 um at 0.15-1.0 MPa (22-145 psi), 30-500 mm/s, from -20 to +70 C, with a fixed TPU bumper at each end. As a rule of thumb, plan on roughly 2262 N of real work at 0.5 MPa, which lifts about 115 kg vertically with a 2:1 margin. The short body saves about 50% of the mounting length of an ISO 15552 profile cylinder, so it slots into presses and gantries where a full-length body will not fit. No magnet is fitted on this code; order the optional -S version if you need CMSE / DMSE switch positions.
Airtac ACED Double-acting Compact Cylinder ACED100X160B Technical Specifications
| Model | Airtac ACED Double-acting Compact Cylinder ACED100X160B |
|---|---|
| Series | ACED compact cylinder |
| Standard | ISO 21287 |
| Bore size | Ø100 mm |
| Stroke | 160 mm |
| Acting type | Double acting, double rod |
| Port size | 1/4" |
| Rod thread | M12×1.75 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed TPU bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACE-series (ISO 21287) datasheet. Body: hard-anodized aluminium alloy; piston rod: S45C carbon steel with hard-chrome plating. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G. A built-in magnet is OPTIONAL — add the -S code to fit CMSE / DMSE position sensors.
Theoretical Output Force (Ø100mm)
| Pressure | Force (both ways) |
|---|---|
| 0.5 MPa | 3770 N |
| 0.7 MPa | 5278 N |
| Max (@1.0 MPa) | 769 kgf |
Double-rod: a rod exits both covers, so output force is equal in both directions (rod-side area used).
Model Code: Airtac ACED Double-acting Compact Cylinder ACED100X160B
| ACED | ISO 21287 compact cylinder (double-rod). |
|---|---|
| 100 | Bore size in mm. |
| ×160 | Stroke length in mm. |
| S | Optional built-in magnet for CMSE / DMSE sensors (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
ACE-family variants: ACE (double acting), ASE / ATE (single acting push / pull), ACED (double rod), ACEJ (adjustable stroke), TACE / TACED (non-rotating twin-guide yoke). Mounting accessories: FA / FB flange, LB foot, CA / CB clevis, CR, SDB pivot, FTC; plus I and Y knuckles. Thread PT (blank) / G.
Where the Airtac ACED Double-acting Compact Cylinder ACED100X160B Is Used
Baler ram for scrap aluminium offcuts
Equal 3769.9 N thrust in both directions lets the ram compact and retract with the same force, and the 160 mm stroke clears a shallow compaction chamber.
Pallet strapping press head
About 2262 N of usable force at 0.5 MPa seats strap buckles on palletized cartons, with the male rod thread picking up a quick-change press tool.
Twin-sided gate drive on a washdown conveyor
A rod on each cover gives a symmetric mount that resists rotation, driving a sliding guard or gate forward and back at up to 500 mm/s.
Is the Airtac ACED Double-acting Compact Cylinder ACED100X160B the Right Cylinder?
At this force class the neighbours matter: the 80 mm bore ACED delivers 2356.2 N at 0.5 MPa, while stepping up to the 125 mm bore gives 5890.5 N. If 3769.9 N both ways covers your clamp or press load, the 100 mm bore is the efficient pick. Remember the piston drifts when air is lost, so add a rod lock or pilot check for a held load. Mount with FA/FB flange, LB foot or FTC brackets plus I/Y rod knuckles on the ISO 21287 face, and specify the -S code if CMSE / DMSE sensing is planned. The 160 mm stroke sits well inside the 300 mm maximum standard stroke for this bore.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short stroke fits the compact body
- ✓ Port/thread type (PT / G)
- ✓ Add -S if you need the magnet for sensors
- ✓ Rod type (female / male B) & mount (FA/LB/CA)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Compact body: keep the stroke short and avoid side load on the rod.
- check Do not dismantle the threaded front/back covers.
- check Keep speed within the rated range; the TPU bumper absorbs stroke-end energy.
- check Installation by qualified personnel per AirTAC docs.
Airtac ACED Double-acting Compact Cylinder ACED100X160B FAQ
Output is EQUAL both ways because a rod exits each cover and both strokes use the rod-side area: 3769.9 N at 0.5 MPa, 5277.9 N at 0.7 MPa, and a maximum of 768.8 kgf at 1.0 MPa. Operating range is 0.15-1.0 MPa (22-145 psi) with a 1.5 MPa (215 psi) proof pressure, air filtered to 40 um, speed 30-500 mm/s and -20 to +70 C.
It is an ISO 21287 compact cylinder with a hard-anodized aluminium body, threaded aluminium covers, an S45C hard-chrome rod and a fixed TPU bumper at each end that only decelerates the stroke ends. The short body saves about 50% of the mounting length of an ISO 15552 profile cylinder. This code has no magnet; order the optional -S version to enable CMSE / DMSE switches, and use FA/FB, LB or FTC mounts with I/Y rod knuckles.
