Airtac ACQ Ultra Thin Air Cylinder ACQ80X20SB
2. Features C-shaped retaining rings for securing cylinder body to front/rear covers, with riveted piston-rod assembly ensuring compactness and reliability;
3. Precision-honed bore surface enhances wear resistance and operational longevity;
4. Extended front cover guiding system improves alignment stability;
5. Space-saving profile maximizes installation flexibility in confined spaces;
6. Integrated sensor grooves along cylinder periphery facilitate seamless sensor mounting;
7. Comprehensive selection of standardized mounting accessories available;
Category: Compact Cylinders | Brand: AIRTAC | Series: ACQ
AirTAC ACQ Ultra-Thin Cylinder ACQ80X20SB Specifications
- Model: ACQ80X20SB
- Series: ACQ Ultra-Thin Compact Cylinder
- Bore size: 80mm
- Stroke: 20mm (±1mm tolerance)
- Mounting type: Basic non-rotating (ISO 6432 standard)
- Operating pressure: 0.05–1.0 MPa
- Temperature range: -20℃ to 80℃
- Port size: G1/4 (BSPP thread)
- Cushioning type: Fixed rubber buffer
- Piston rod thread: M16×1.5 (external)
- Material: Anodized aluminum alloy body, CR12MoV chrome-plated rod
- Seal material: High-temperature NBR (Nitrile rubber)
- Weight: 1.25kg ±2% (without accessories)
- Dimensions:
- Length: 149mm (extended length: 169mm)
- Width: 96mm (mounting face to port side)
- Height: 96mm (including rod end)
- Lubrication: Pre-lubricated (Grease-free operation)
- Repeat accuracy: ±0.5mm
- Max theoretical thrust: 502N @0.7MPa
- Air consumption: 0.65L/stroke @0.5MPa
- Magnetic switch compatibility: D-A93 series (optional)
The ACQ80X20SB redefines space efficiency with its 30% slimmer profile compared to standard cylinders, featuring dual-action operation and precision-ground guide rods for anti-rotation stability. Its enhanced wear-resistant design incorporates a chrome-plated piston rod with multi-layer sealing (primary polyurethane + secondary NBR) for leak-proof performance in high-cycle applications. Requires 5-40μm filtered compressed air with ISO 8573-1:2010 class 3 air quality.
- High-density PCB board clamping in electronics assembly
- Precision paper feeding mechanisms in printing machinery
- Vertical lift assists in medical bed articulation systems
- Compact sorting actuators in pharmaceutical packaging lines
- Space-constrained automation in semiconductor wafer handling
Installation best practice:
Maintain perpendicular alignment within 0.2mm/m parallelism tolerance during mounting.
For horizontal installations exceeding 500mm stroke, use rod support guides to prevent sagging.
Lubricate every 500,000 cycles using ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | ACQ80X20SB |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Bore Diameter | 80 mm |
| Stroke | <20mm> |
