Airtac ACQ125 Slim Cylinder ACQ125X150SB
1. Compliant with JIS (Japanese Industrial Standards) specifications;
2. Features C-shaped retaining ring for cylinder body and end cover fixation, ensuring compactness and reliability;
3. Precision-machined bore with hard anodized treatment for enhanced wear resistance and durability;
4. Asymmetric bidirectional sealing structure on piston for compact dimensions and integrated oil storage capability;
5. Space-saving profile design to optimize installation space utilization;
6. Built-in sensor grooves along the cylinder periphery for effortless sensor integration.
Category: Slim Cylinder , Brand: AIRTAC , Series: ACQ125
AirTAC ACQ125X150SB Compact Cylinder Specifications
- Model: ACQ125X150SB
- Type: ISO 6432 compliant thin-series double-acting cylinder
- Bore size: 125mm
- Stroke: 150mm (±0.5mm tolerance)
- Operating pressure: 0.1–0.9 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion at both ends
- Piston rod material: Chrome-plated stainless steel (SUS304)
- Tube material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber) with wear-resistant ring
- Port size: G1/2 (ISO standard tapered thread)
- Mounting style: Basic type (optional flange/clevis mounts available)
- Weight: 3.8kg (excluding accessories)
- Dimensions:
- Length: 265mm (minimum retracted length)
- Width: 140mm (including mounting brackets)
- Height: 140mm (square profile design)
- Piston rod diameter: 25mm
- Theoretical thrust: 1,227N @ 0.6MPa
- Lubrication: Pre-lubricated (recommended relubrication cycle: 2,000km)
This ultra-compact cylinder combines high rigidity and space efficiency, featuring a 45% reduced installation height compared to standard cylinders. The square body design enables direct sensor mounting and improves heat dissipation. Precision honed tube with integrated scrape wiper prevents contamination ingress. Requires 5-40μm filtered compressed air.
- High-density robotic tool changers in automotive assembly
- Vertical lift mechanisms for semiconductor wafer handling
- Press-fit operations in consumer electronics manufacturing
- Modular conveyor system actuators
- Compact clamping fixtures for CNC machining centers
- Align piston rod axis within 0.2mm angular misalignment tolerance
- Maintain 1.5mm minimum clearance around cylinder body for thermal expansion
- Use M6 mounting screws with 12Nm torque limit (included in kit)
- For vertical mounting: Install rod end downward to prevent seal wear
| Property | Property Value |
|---|---|
| sku | ACQ125X150SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 125mm |
| Stroke | 150mm |
