Airtac ACQ125 Slim Cylinder ACQ125X175SB
1. Compliant with JIS (Japanese Industrial Standards) specifications;
2. Features C-shaped retaining ring for cylinder body and end cover fixation, ensuring compactness and reliability;
3. Precision-machined bore with hard anodized treatment for enhanced wear resistance and durability;
4. Asymmetric bidirectional sealing structure on piston for compact dimensions and integrated oil storage capability;
5. Space-saving profile design to optimize installation space utilization;
6. Built-in sensor grooves along the cylinder periphery for effortless sensor integration.
Category: Slim Cylinder , Brand: AIRTAC , Series: ACQ125
AirTAC ACQ125X175SB Thin Cylinder Specifications
- Model: ACQ125X175SB
- Bore size: 125mm
- Stroke: 175mm
- Operating pressure: 0.1–0.9 MPa
- Cushion type: Adjustable pneumatic cushion (both ends)
- Mounting style: Basic type (Standardized ISO/VDMA mounting options available)
- Port size: G1/2 (BSPP thread)
- Ambient temperature: -20℃ to 80℃
- Piston speed: 50–800 mm/s
- Material: Aluminum alloy cylinder tube, hard-anodized piston rod (SUS304)
- Seal material: NBR (Nitrile rubber)
- Weight: 4.8 kg (dry, without accessories)
- Dimensions: 300mm(L) × 140mm(W) × 140mm(H) (Max extended length)
- Rod thread: M20×1.5 (External)
- Protection class: IP65 (Dust-tight & water jet resistant)
- Lubrication: Pre-lubricated (Use ISO VG32 turbine oil if maintenance required)
Ultra-compact profile cylinder with 25% reduced length compared to standard models, featuring dual anti-rotation guides for precise linear motion. The hardened stainless steel rod and double-seal structure ensure 2,000km minimum service life under rated conditions. Optimized for high-speed applications with minimal vibration transmission.
- High-density PCB board clamping/pressing systems
- Vertical packaging machine sealing jaws
- Automated warehouse stacker position correction
- Glass panel vacuum lifting systems
- High-speed sorting gate actuators
Installation tip:
Maintain ≤0.1mm/m alignment tolerance during mounting. For vertical installations,
use rod-down orientation to prevent condensate accumulation. Apply 2-3 drops of
AirTAC PNEUMA Oil No.2 weekly in high-cycle applications (>500 cycles/min).
| Property | Property Value |
|---|---|
| sku | ACQ125X175SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 125mm |
| Stroke | 175mm |
