Airtac ACQ125 Slim Cylinder ACQ125X200SB
$266.10
Regular price
$273.60
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
ACQ125X200SB
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
ACQ125 Slim Cylinder
1. Compliant with JIS (Japanese Industrial Standards) specifications;
2. Features C-shaped retaining ring for cylinder body and end cover fixation, ensuring compactness and reliability;
3. Precision-machined bore with hard anodized treatment for enhanced wear resistance and durability;
4. Asymmetric bidirectional sealing structure on piston for compact dimensions and integrated oil storage capability;
5. Space-saving profile design to optimize installation space utilization;
6. Built-in sensor grooves along the cylinder periphery for effortless sensor integration.
Category: Slim Cylinder , Brand: AIRTAC , Series: ACQ125
Installation guidelines:
Maintain 0.5-1mm clearance between cylinder body and mounting surface for thermal expansion.
Use M8×1.25 mounting bolts (grade 8.8 or higher) with maximum 25N·m torque.
Lubricate rod end weekly with ISO VG32 hydraulic oil in high-cycle applications.
1. Compliant with JIS (Japanese Industrial Standards) specifications;
2. Features C-shaped retaining ring for cylinder body and end cover fixation, ensuring compactness and reliability;
3. Precision-machined bore with hard anodized treatment for enhanced wear resistance and durability;
4. Asymmetric bidirectional sealing structure on piston for compact dimensions and integrated oil storage capability;
5. Space-saving profile design to optimize installation space utilization;
6. Built-in sensor grooves along the cylinder periphery for effortless sensor integration.
Category: Slim Cylinder , Brand: AIRTAC , Series: ACQ125
AirTAC ACQ125X200SB Compact Cylinder Technical Details
- Full model: ACQ125X200SB
- Series: ACQ Ultra-Thin Cylinder Series
- Bore size: Φ125mm
- Stroke: 200mm
- Operating pressure: 0.05-1.0 MPa
- Medium: Clean dry air (lubricated or non-lubricated)
- Ambient temperature: -20℃ to 80℃
- Cushioning: Adjustable rubber bumper (both ends)
- Mounting style: Basic type (no built-in mounts)
- Port size: G3/8 (BSPP thread)
- Piston material: High-grade aluminum alloy (hard anodized)
- Rod material: SUS304 stainless steel
- Seal type: NBR (standard), optional Fluorocarbon
- Repeat accuracy: ±0.5mm
- Weight: 7.8kg (dry)
- Dimensions: 325mm(L) × 145mm(W) × 145mm(H)
- ISO certification: ISO 6432 compliant
- Protection class: IP54 (standard sealing)
High-performance thin-profile cylinder optimized for space-constrained automation systems. Features precision-machined guide bearings for anti-rotation stability and dual piston seals for leak prevention. Pre-lubricated design supports 5,000km service life under normal operation.
Industrial Applications:
- PCB handling robots in electronics manufacturing
- Vertical injection molding machine ejectors
- Automotive welding fixture positioning
- Lithium battery pressurization systems
- Semiconductor wafer transfer mechanisms
Installation guidelines:
Maintain 0.5-1mm clearance between cylinder body and mounting surface for thermal expansion.
Use M8×1.25 mounting bolts (grade 8.8 or higher) with maximum 25N·m torque.
Lubricate rod end weekly with ISO VG32 hydraulic oil in high-cycle applications.
| Property | Property Value |
|---|---|
| sku | ACQ125X200SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 125mm |
| Stroke | <200mm> |
